Normal Precision Gear Sumore Wooden Box 50mm Univereal Milling Machine

Normal Precision Gear Sumore Wooden Box 50mm Univereal Milling Machine

US$2,600.00-5,500.00 1 set (MOQ)

Basic Info.

Model NO.
SP2241
Type
Worktable Milling Machine
Object
Gear
Structure
Vertical
Milling Cutter Type
End Mill
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
Normal Precision
Certification
CE
Condition
New
Spindle Taper
ISO40(V) ISO40(H)
Distance From Spindle to Table
90~370mm
Spndle Travel
127mm
Z-Axis Travel(Headstock)
800mm
X-Axis Travel(Cross)
350mm
Y-Axis Travel(Longitudinal)
400mm
Weight(Net/Gross)
1250/1350kg
Packing Size
1600X1450X2200mm
Processing Material
Copper,Aluminium,Metal,Glass
Key Word
Universal Vertical Drilling and Milling Machine
Transport Package
Wooden Box
Specification
50mm
Trademark
SUMORE
Origin
China
HS Code
8459619000
Production Capacity
1000set

Product Description

Product Description
universal milling machine fresadora universal turret milling machine SP2241 ZAY series Universal vertical milling drilling machine price China metal manual bridgeport universal gear drilling milling machine 50mm horizontal vertical universal milling machine fresadora universal cutter mini horizontal vertical milling machine for hobby mini manual vertical milling and drilling machine price SUMORE small milling drilling machine cheap mini torno fresadora Universal Vertical Drilling and milling machine for metal Hobby desktop mini desktop mill drill milling machine Mini metal milling machine made in China, but same quality with Japanese made milling machine Bench Type mini universal Milling Machine is one of our most economic and durable mini universal Milling Machine. It sells very well; it is new condition not used universal Milling Machine. And it is small in size and delicate in design. This milling machine is made in China, but with same quality of Japan milling machine. The main features are as below:
Quick detais
1.Spindle taper: ISO40(V) ISO40(H)
2.Horizontal milling dia.:100mm
3.Distance from spindle to table.:90~370 mm
4.Head tilt left & right:+45°
5.Spindle speed: 90-2000rpm/38-1310 rpm
6.Working tabel:280*1270mm
7.Power:3HP(V) 2200W
Features/Advantages
1.Three axis hardened treatment, high rigidity.2.vertical horizontal multi-functional ,drilling ,milling, boring operation.3.X axis mechanical feed,Y.Z axis can be added the device4.Gear transmission milling head, stable transmission, compact structure ,easy maintenance, easy to operate
5.Uses standardized assemblies from the VH milling machine universal use as milling machines and drill press6.Easily shiftable gear drive ensures power transmission without losses7.With V-belt spindle drive and gear spindle drive8.Head swivels into the horizontal level on both sided via crank and toothed gear, easy activation of manual micro-feed for the spindle quill
9. Drilling Milling machine adopts belt drive, low noise, suitable for drilling, expanding, reaming and milling on various common materials
10.Drilling Milling machine has 12 speeds and a wide range of speeds, suitable for processing various commonly used soft and hard materials
11. Spindle box and worktable can be raised and lowered, and can also be rotated around column, which expands processing range
12.This machine tool can be equipped with multi-axis machines
Product Parameters
Model
SP2229
Drilling Capacity
30 / 50 mm
Boring Capacity
120 mm
Longitudinal Axis Travel (X)
600 mm
Cross Axis Travel (Y)
260 mm
Headstock Axis Travel (Z)
120 mm
Effective Table Size
1,120 x 280 mm
Spindle Taper
MT4 / R8 / ISO30 / ISO40
Spindle Speed Range
90 - 2,000 / 38 - 1,130 rpm
Distance Between Spindle to Table
490 mm
T-slot Amount
3
Head Tilt Angle (Left / Right)
45° / 45°
Motor Power
850 / 1,500 / 2,200 w
Voltage and Frequency
Customrized
Overall Dimension (LxWxH)
1,400 x 1,630 x 2,350 mm
Net Weight
1,200 kg
Gross Weight
1,350 kg


Company Profile
As the professional and experienced manufacturer of lathe, mill , drill , cnc and other tools ,Shanghai SUMORE Industrial Group has been in this filed for more than 20 years.
We have got the certificates of CE, GS ,Rohs , UL ,etc . Also we have been in business with GSK ,Siemens ,Faunc and other famous companies within 50 countries all over the world.
Whether you need the standard or the customerised products , please contact us directly . Our professional and experienced engineers and after sale service team will meet your needs.
Hope to cooperate with you!
