1325 Excellent Quality Mrble Slab Cutter Granite Automatic CNC Cutting 1325 CNC Stone Engrave Machine
| US$6,400.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
PLC-1325
Application
Construction, Mineral Industry, Stone Industry
Source Voltage
380V
Automation
Automatic
Cutting Ability
High Speed
Control
PLC
Certification
ISO, CE
Output
7 Sqm Per Hour
Color
Yellow
Transport Package
40FT Hq Container for 1 Set
Trademark
wanlong
Origin
Quanzhou, China
HS Code
8464101000
Production Capacity
100sets Per Year
Product Description
1325 Excellent Quality Mrble Slab Cutter Granite Automatic cnc Cutting 1325 Cnc Stone Engrave Machine:This machine is mainly for Granite Engraving, it can make the letters and different nice pictures on stone. It's of Hyanid Servo Motor Drive, High Precision bevel Drive, and the Screw is of Taiwan TPI2505.lt uses the Mono-block structure, with special back installation, Steel structure, and the surface with electroplating treatment.
lt can do the Automatic Oil filling, completely elcosed Dustproof.
| Machine Details | ||
| No. | Part | Details |
| 1 | Machine Structure | Heavy square pipe welding, aging treatment |
| 2 | X axis Traveling Area | 1300mm |
| 3 | Y axis Traveling Area | 2500mm |
| 4 | Z axis Traveling Area | 600mm |
| 5 | Transmission | Z axis Taiwan Ball Screw and XY axis gear Transmission |
| 6 | Guide Rail on X Y Z axis | Square guide rail, 25mm |
| 7 | Table | Stainless steel water tank table |
| 8 | Drive & Inverter | Stepper motor & drivers |
| 9 | Spindle Power | 5.5kw rotate spindle*2 |
| 10 | Software | Type3, Artcam Ucancam |
| 11 | Control System | NC Studio control system |
| 12 | Electric Box | Large independent electric box |
| 13 | Voltage | 3-phase 380V 60Hz |
| Technical Specification | ||
| No. | Model | 1325 |
| 1 | Spindle Power | 5.5kw |
| 2 | Spindle Speed | 0-24000RPM |
| 3 | Working Area | 1300*2500mm |
| 4 | Z-axis Height | 600mm |
| 5 | Travelling Positioning Accuracy | ±0.03/300mm |
| 6 | Positioning Accuracy | ±0.03mm |
| 7 | Max. Rapid Travel Rate | 33000mm/min |
| 8 | Max. Working Speed | 24000mm/min |
| 9 | Computer Interface | USB |
| 10 | Command Language | G Code |
| 11 | Working Voltage | 3-phase 380V 60Hz |
