Tongda Tdb High Temperature Double Overflow Fabric and Cloth Dyeing Machine

Tongda Tdb High Temperature Double Overflow Fabric and Cloth Dyeing Machine

US$35,000.00-300,000.00 1 Set (MOQ)

Basic Info.

Model NO.
TDB
Material
Cotton Fabric
Voltage
220V
Certification
CE, ISO9001: 2000
Warranty
1 Year
Customized
Customized
Condition
New
After-sales Service
1year
Name
Fabric & Cloth Dyeing Machine
Brand
Tongda
Video Outgoing-Inspection
Provided
Core Components
PLC, Motor, Pump
Machinery Test Report
Provided
Transport Package
Export Package
Specification
5490*1700*2300mm
Trademark
tongda
Origin
China

Packaging & Delivery

Package Size
549.00cm * 170.00cm * 230.00cm
Package Gross Weight
1000.000kg

Product Description


Fabric Dyeing Machine
Suitable for dyeing various cloths, including those made of natural fibers (cotton, linen, silk, wool) and their blends with chemical fibers, as well as chemical - fiber - based woven, knitted, stretch, light/thin and heavy fabrics like polyester, nylon and spandex ones.

TDO Super Environmental U-Flow Dyeing Machine
Inner interactive plaiting system (PDM Patent), maximum increase the loading capacity of fabric storage chamber. Innovative "U" shape fabric dyeing nozzle system, improve fabric even dyeing, avoid fabric crease mark.

TDYL Energy-Saving and Environ- ment Protection Dyeing Machine
Low water consumption,very low liquor ratio 1:3.5 ~ 1:5, reduce emissions; Save steam consumption, reduce heat consumption; Save power consumption; Save pigments and additives; Dyeing equilibrium; Reduce production costs.


TDME Allfit Medium Batch Dyeing Machine Series
The machine is designed for small batch if piece dyeing. Low liquor ratio. Small power consumption and fast fabric turn around time ensure the dyeing quality and result. Production dyeing recipe and process technique can be applied directly without modification. It is available in 6 sizes namely 2kg, 5kg, 5kg, 10kg, 30kg, 50kg and 100kg.


TDC High Temperature High Pressure Dyeing Machine
The new nozzle and fabric handling systems boost cloth capacity and speed, lower the bath ratio, ensuring uniform dyeing and a great hand feel. This machine, highly adaptable, is ideal for dyeing cotton, cotton blends, and chemical fiber fabrics.


TDA High Temperature and Rapid Spary Dyeinig Machine
Extra large capacity: a. Fast return on investment b. Reduce the difference between batch dyeing vats C. Improve production efficiency. Flexible water flow minimizes the surface impact on high-grade fabrics to ensure no linting and no yarn distortion. Unique elbow design can achieve the purpose of no dead angle, minimum expansion force and minimum bath ratio.

TDB High Temperature Double Overflowdyeing Machine
Adopting a unique overflow - jet dual - use nozzle design, users can switch water flow types (low - pressure, large - volume overflow or high - pressure, high - speed jet) by changing nozzles according to fabric types. Suitable for a wide range of woven and knitted fabrics, it offers excellent dyeing quality, low cost, and high efficiency, with applicable fabric weights from 60 - 600g/m2.

TDME38 Normal Temperature Dyeing Macihine
As a high-end new generation environmentally friendly dyeing machine, TDME38 is developed by integrating the latest technology and manufacturing processes. This machine can achieve a low bath ratio of 1:5, a high output with a maximum weight of 250 kg per tube, and a fast cloth speed of up to 350 meters per minute, without affecting the quality of the dyed fabric.
Main technical parameters
Model Nominal capacity Power of main pump (KW) Dimensions
(Kg) (Lbs) L (mm) W (mm) H (mm)
TDO 1P 250 - 300 550 - 660 7.5 3670 4850 3470
TDO 2P 500 - 600 1100 - 1320 15 4630 4850 3545
TDO 3P 750 - 900 1650 - 1980 22 6220 4880 3545
TDO 4P 1000 - 1200 2200 - 2640 30 7220 4880 3748
TDO 6P 1250 - 1500 2750 - 3300 45 9384 4788 3748
TDO 8P 1500 - 1800 3300 - 3960 55 12300 4800 3800

FAQ
(1) Q: Why Choose Our Company?
A: History: TONGDA Textile Machinery Group was establish in 1952. Now have more than 65 years old history. Main Products: TONGDA Group specializes in design, manufacturing, and marketing of a wide range of Textile machinery, it has seven branch companies, mainly produces ring spinning frame, roving frame, weaving machine (water Jet loom/Air jet loom/rapier Loom), warping machine, quilting machine and nonwoven machine. We provide design for complete line of spinning mill for cotton yarn, polyester yarn, wool yarn, flax/linen yarn, machines including blow room, carding machine, draw frame, roving frame, ring frame, winding machine, open end spinning machine and the air conditioning system and waste collection system for spinning mill. We also provide workshop layout design and trench design, and air pipe layout design.
(2) Q: How's the after-sale service?
A: We offer engineers available to service overseas under merchandiser's supervision and translation.
(3) Q: Are you available for on-the-spot invitation?
A: We do welcome our new and old friends come here to have a visitation. Besides, we would send you our exposition and relative information to promote a face-to-face meeting if you'd like to.
(4) Q: Is the price offered changeable?
A: We offer reasonable price for every client, and the price is changeable according to purchasing amount.
(5) Q: How about the quality?
A: The main subassembly and raw materials are all supplied by large companies. Key parts are research and developed by our own staff. Professional assembly line work and strict quality test system can ensure your high quality requirement.
(6) Q: Are you a manufacturer or Trade Company?
A: We are a professional manufacturer holding our own International Trade Department, for that we can better understand customer's needs and offer a reasonable price.
(7) Q: Product /Quality Guarantee and After Sale Service?
A: 1 year warranty for the International standard. We are work online 24 hours. If you have any questions about our machine you can contact us.
(8) Q: One-stop Service:
A: We have R&D department including more than 100 engineers which are improving and enlarging our supply range.
(9) Q: Certification?
A: TONGDA is an ISO9001, ISO14001, and ISO13485 company. The products are designed to meet the technical standards of 3C and CE. All the products are certified by the Industry Administration Authority. TONGDA will continue to strive to be a stronger leader in the global market of Cotton machinery and Spinning machinery.
