Large Diameter Hose for Trenchless Rehabilitation Pipe in Liner 200
| US$2.00-8.00 | 1,000 Meters (MOQ) |
Basic Info.
Model NO.
pipe in liner 200
Compound Material
Fabric Reinforced Flexible Plastic Pipes
Material
PE-Al-PE
Installation and Connection
Clamping Type Installation
Technology of Plastic Composite Pipe
Hot Dip
Base Pipe of Plastic Composite Pipe
Welded Steel Pipe
Internal Coating Materials of Plastic Composite Pipe
Polyethylene Coating Steel Pipe
Plastic Composite Pipe Coating Form
Inner Coating
Plastic Composite Pipe Model
GS-—X-SP-T-EP
Steel Skeleton PE Pipe Use
Municipal
Aluminium Plastic Compound Pipe Use
Water Heater Tube
Steel Plastic Composite Pipe Model
GS-—X-SP-T-EP
Aluminium Plastic Compound Pipe Material
Crosslinked Polyethylene Aluminum Composite Pipe
Wp
4.0MPa
Transport Package
Cartons
Specification
pipe in liner 200
Trademark
ZYfire
Origin
China
HS Code
40093100
Production Capacity
1000000m/Month
Product Description
Liner 200Raw Materials:
High tenacity fabric reinforcement layer,
abrasion resistance PE/PVDF cover, Modified TPU tube.
Oil Solution
| Description | Parameter |
| Host Pipe ID | 80mm ~ 800mm (3" ~ 32") |
| Max. Operation Pressure | 1.0Mpa ~ 8.0Mpa |
| Max. Bursting Pressure | 3.0Mpa ~ 24Mpa |
| Max. Length of Installation | ≥ 4000m (13,200ft) |
| Wall Thickness | 4mm ~ 8mm |
| Abrasion Resistance (DIN53516) | 10.5mm3 |
| Temperature of Media | PE: -40ºC ~ 70ºC PVDF: -40ºC ~ 120ºC |
| Installation Mode | Fold in U-sharp |
| Pulling Speed | Up to 400m/h |
| Service Life Duration | 50years |
| **All the above technical parameters are depends on diameter. | |
