Precision CNC Lathe Tool Center for Advanced Machining Solutions

Precision CNC Lathe Tool Center for Advanced Machining Solutions

US$3,500.00-46,895.00 1 Piece (MOQ)

Basic Info.

Model NO.
VMC 855S
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Linear Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
Economical CNC Machine Tools
Certification
ISO 9001
Condition
New
Process G Range Xyz
800X550X550mmmm
Spindle Nose to Table
120-670mm
Spindle Center to Column Surface
595mm
Machine Size
2500X2000X2200mm
Weight
4800kgs
Spindle Taper
Bt40
Spindle Speed
Direct 12000rpm
Table Size
1000X550
T Slot
3X18X130
Max Load
500
Transport Package
Steel Case, Plywood Case
Specification
table size 1000*500mm
Trademark
Suji
Origin
China
HS Code
8457101000
Production Capacity
1000sets/Year

Packaging & Delivery

Package Size
200.00cm * 100.00cm * 100.00cm
Package Gross Weight
28000.000kg

Product Description

Company Profile
Suji Intelligent Equipment Jiangsu Co., Ltd
Suji Intelligent Equipment Jiangsu Co., Ltd was established in 2018 and is located in Jiangsu Shuyang National Economic Development Zone. We specialize in CNC machine tools, vertical machining centers, and offer comprehensive services including production, research and development, sales, and service. Our professional technical team has years of experience in CNC machine tool manufacturing, ensuring high-quality and cost-effective machine tools for our customers.
Major Products:
Vertical machining center series
Horizontal machining center series
Gantry machining center series
Flat rail CNC lathe
Inclined rail CNC lathe

Our machine tools are designed for high speed, rigidity, performance, and efficiency, making them the preferred choice for industries such as communication, consumer electronics, medical, LED, automotive, aerospace, and more.
We have a strong research and development team with years of manufacturing experience, and we are ISO9001 quality system certified. Quality and service are at the core of our business philosophy, focusing on creating value for customers, opportunities for employees, and benefits for society. Our service concept revolves around professionalism and sincerity, ensuring high-quality pre-sale, sale, and after-sales service, along with technical support for our customers.
We are committed to meeting the needs of our customers and markets, aiming to develop together with our partners and create a better future.
Product Description
Product Parameters
S/Model Unit VMC640S VMC850S VMC855S VMC1160S VMC1370S VMC-1580S
Machining Range
X axis travel mm 600 800 800 1100 1300 1500
Y axis travel mm 400 500 550 600 700 800
Z axis travel mm 450 500 550 600 700 700
Spindle nose to table mm 150-600 150-650 120-670 120-720 110-810 130-830
Spindle center to column mm 470 545 595 645 750 810
Workbench size
Table Dimension mm 700x420 900x500 1000x550 1200x600 1400x700 1800x800
T-slot Dimension mm 3x14x120 3X18X130 5X18X90 5X18X100 7X18×100 22X5X140
Max Load kg 250 500 500 800 1000 1500
Spindle
Taper BT40 BT40 BT40 BT40 BT40/BT50 BT40/BT50
Max Speed rpm Direct 12000 8000-1000rpm
Infeed System
G00 fast infeed(Axis X/Y/Z) m/min 48/48/48 48/48/48 48/48/48 36/36/36 36/36/36 36/36/36
G01 cutting infeed m/min 1-10000 1-10000 1-10000 1-10000 1-10000 1-10000
Tool Magazine
Type type Disc Disc Disc Disc Disc Disc
Capacity unit 24 24 24 24 24 24
Machine Dimension
Length mm 1800 2300 2500 3200 3600 3850
Width mm 2400 2800 2000 2400 3300 3100
Height mm 2300 2700 2200 2800 2900 2900
Weight kgs 4600 4600 4800 7500 10500 12000

Brands of Main Parts
Part Name Origin Manufacturer Model
CNC system FANUC, Japan FANUC 0i-MF PLUS(Type 3)
Servo feed motor FANUC, Japan FANUC
Servo spindle motor FANUC, Japan FANUC
Servo integrated driver FANUC, Japan FANUC
Spindle group Taiwan Royal/Kenturn BT40-φ150
Roller screw Taiwan HIWIN/PMI FDC4012
Linear guide rail Taiwan HIWIN/PMI 45#/45#/45#
Spindle bearing China mainland NSK
Unclamping Cylinder Taiwan Haocheng 4.5T
Disk type tool magazine Taiwan Ammach/Tokuda/Okada BT40-24T
Locking nut Taiwan Svit M30×1.5P/ M35×1.5P
coupling Japan Sanmu
heat exchanger Japan Miki Pully EA-02W/220V
Screw bearing Japan/Germany NSK/FA.G 30TAB062
Oiling machine Taiwan Ishan
Main electrical components France Schnneider
Pneumatic components Taiwan TWSNS
Chain chip conveyor China mainland SUJI
