14" X24" Variable Speed Woodturning Lathe with Delta Inverter (MC1424VS)

14" X24" Variable Speed Woodturning Lathe with Delta Inverter (MC1424VS)

US$1,500.00 50 Pieces (MOQ)

Basic Info.

Model NO.
MC1424VS
Voltage
380V
Tool Holder
1
Automatic Grade
Manual
Precision
High Precision
Setting Mode
Floor-type
Controlling Mode
Artificial
Power Source
Electric
Processing Accessory
Face Plate
Certification
CE
After-sales Service
1year
Swing Over Bed
14"
Distance Between Centres
24"
Face Plate
4"
Tool Rest
8"
Transport Package
Carton or Plywood Case
Specification
CE
Trademark
BURT
Origin
China
Production Capacity
5000/Month

Product Description

Specifications:
01) Description: 14"x24" wood lathe with Rotatable headstock
02) Motor(Input W): 750W (with 750W inverter)
03) No. of Speed: Variable
04) Spindle Speed: 0~1200rpm Low Speed, 0~3200rpm High Speed
05) Swing Over Bed: 368mm(14.5")
06) Distance Between Centers: 24.5" (620mm) or 47" (1200mm) with optional extension bed
07) Drive Spindle: M33X3.5 or 1"8RH thread
08) Headstock and Tailstock Taper:MT2#
09) Face Plate: 152mm(6")
10) Tool Rest: 200mm(8")
11) Packing Size(mm): 1125X580X515
12) NW/GW: 137/165KGS
13) Units per 20-foot container:80 pcs

Main features:
* Electronic Inverter Variable Speed Lathe with 750W TAIWAN DELTA brand Inverter
* Two belt ratios for high torque when turning large diameters
* Digital speed display on headstock
* Quick belt change construction headstock
* All cast iron constuction for high stability and vibration free running
* Cast iron stand with provision for a shelf
* Headstock rotates for outboard turning
* 36 Indexing Positions Function
* With Forward/Reverse running function
* Magnetic control box can be positioned where required
01) Description: 14"x24" wood lathe with Rotatable headstock
02) Motor(Input W): 750W (with 750W inverter)
03) No. of Speed: Variable
04) Spindle Speed: 0~1200rpm Low Speed, 0~3200rpm High Speed
05) Swing Over Bed: 368mm(14.5")
06) Distance Between Centers: 24.5" (620mm) or 47" (1200mm) with optional extension bed
07) Drive Spindle: M33X3.5 or 1"8RH thread
08) Headstock and Tailstock Taper:MT2#
09) Face Plate: 152mm(6")
10) Tool Rest: 200mm(8")
11) Packing Size(mm): 1125X580X515
12) NW/GW: 137/165KGS
13) Units per 20-foot container:80 pcs
Optional Accessories:
* With extra extension bed MC1624-EX+OTR available as optional accessory, which could extend the total working lenght to 1200mm(47") or Extend the bowl turning capacity to 720mm(28")
MC1424VS+MC1624-EX+OTR
