8m Width Plastic Waterproof Membrane Extrusion Machine
| US$50,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
JS-TGM8000
Product Type
PE Board
Board Layers
Multilayer
Screw No.
Single-screw
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Customized
Customized
Condition
New
Thickness
0.3-5mm
Transport Package
by Pallets
Specification
8000mm
Trademark
JUNSHENG
Origin
Jiaxing
HS Code
84778000
Production Capacity
10 Sets/Month
Product Description
8m Width Plastic Waterproof Membrane Extrusion MachineJunsheng Brand machines, guarantee is 2 years and we offer Turn-key project.
Width: 8000mm
Layer: 1-3 PE layers, with or without geotextile lamination
Brief Introuction of Junsheng HDPE Geomembrane Line:
- Geomembrane thickness 0.3-5mm, width up to 8000mm.
- Cast film, not blow film, film stronger and unique thickness.
- 100% recycled material, low production cost.
- 2 extruders co-extrusion with 3-layer T die, automatic control
- Online geotextile lamination
Main Technical Specification of Junsheng Waterproof Sheet Machine:
| Model | JS-TGM3000 | JS-TGM5000 | JS-TGM6000 | JS-TGM8000 | |
| Suitable material | HDPE, PP | ||||
| Screw dia. | mm | 150 | 150×2 | 150×2 | 180×2 |
| L/D ratio | L/D | 33:1 | 33:1 | 33:1 | 33:1 |
| Product width | mm | 3000 | 5000 | 6000 | 8000 |
| Product thickness | mm | 0.2-2.5 | |||
| Output | Kg/h | 500 | 1000 | 1000 | 1200 |
| Line speed | m/min | 4--6 | 4--8 | 4--8 | 4--10 |
| Installed capacity | KW | 320 | 550 | 550 | 680 |
| Power consumption | KW | 160 | 300 | 300 | 400 |
| Dimensions (L×W×H) | m | 22×5×2.8 | 24×7×3.5 | 24×7.5×3.5 | 25×10×3.5 |
| Total weight | T | 19 | 25 | 28 | 35 |
