Factory Wholesale 5km Long Range Lora Transmitter 433MHz/868MHz/915MHz Controller Universal Remote Control

Factory Wholesale 5km Long Range Lora Transmitter 433MHz/868MHz/915MHz Controller Universal Remote Control

US$10.00
20-199 Pieces
US$9.00
200-999 Pieces
US$8.50
1,000+ Pieces

Basic Info.

Model NO.
KLR5000-N
Certification
ISO9001, RoHS, FCC, CE
Frequency
433MHz
Material
Plastic
Transmission Distance
5000 Meters
Type
Button
Universal
Universal
Voltage
12V
Weight/G
100g
Working Voltage
DC9V
Working Current
65mA
Receive Current
16mA
Standby Current
5ua
Working Frequency
434MHz (Can Customize 868, 915MHz)
Modulation Mode
Fsk (FM)+ Lora(Spsp)
Receiving Sensitivity
-148dBm
Dimension
158*42*20 mm
Control Distance
6000m (Open Area, Match with Kl-K400la)
Signal Transmission
RF Remote Control
Transport Package
Plastic Bag & Carton
Specification
158*42*20mm
Trademark
Kelvin
Origin
Shenzhen, China
HS Code
8526920000
Production Capacity
50000

Packaging & Delivery

Package Size
15.00cm * 15.00cm * 5.00cm
Package Gross Weight
0.100kg

Product Description

Blue shell long range 433MHz remote control KL5000-12
1. Overview
KL5000-N is a super far distance bidirectional communication remote control series that developed by our company lately. There are 6 models according to different buttons sum 1,2,4,6,8,12. It adopts spread spectrum communication technology to increase the anti-jamming performance. American imports chipset and strict inspection ensure the quality and reliability. The measured operation range can be more than 6000m when the remote control is working with the specialized receiver module.
If the bidirectional mode is selected, the remote will instantly receive a feedback from the receiver.
2. Operation
1) Matching code
Press learning button on the receiver module and hold on for 3 seconds, LED indicator lights. Then press any button on the remote control. When LED flashes twice, matching successfully.

2) Feedback Set
Short-circuit S3 on the PCB of remote control, it receives feedback.
When it receives the feedback, it will make a sound as "Di---"
Otherwise, it does not.

Note:
If feedback is selected, the remote control is going to receiving status after the button is released. The remote will not work whichever button is pressed. It will return normal in 1 second.

Please turn off the remote control when it is not in use for extended periods.
