Portable Deep Well1.5kw Solar Submersible Water Pump System Solar Water Pump for Agriculture

Portable Deep Well1.5kw Solar Submersible Water Pump System Solar Water Pump for Agriculture

US$299.00
1-99 pieces
US$199.00
100+ pieces

Basic Info.

Model NO.
NK-SBLDC_220/15
Max.Head
>150m
Max.Capacity
100-200 L/min
Driving Type
Motor
Material
Stainless Steel
Structure
Multistage Pump
Assembly
Liquid Pumps
Power
Solar Energy
Start Up
Magnetic Pump
Type
Submersible Pump
Application
Submersible Pump, Sewage Pump
Industry
Agriculture
Media
Sewage Pumps
Performance
Wear Pump
Theory
Rotary Pump
Certification
CE TUV IEC RoHS
Daily Water Flow
5.5-28 M3
Horsepower
2HP
Voltage
110-240V
Pressure
High Pressure
Adapting Well Diameter
100-550m
Solar Power (W)
4kw
Maximum Flow Rate
80m3/Hrs
Maximum Head
150m
Output Frequency
0.50Hz/60Hz
Cooling Method
Fan Cooling
Solar Controller
MPPT Controller, 48V/96V220V Three Phase
Transport Package
Carton
Specification
2KW 2.2m3/Hrs 98m
Trademark
Namkoo
Origin
Guangdong, China
Production Capacity
30000 Set/Sets Per Month

Product Description

Portable solar water pump 1.5kw for irrigation popular in japan
WORKING THEORY
>>> The DC solar pump system are mainly made of solar panel, solar controller and Dc solar pump and ect. The load is 3-phase BLDC motor or pump. The system does not need battery for storing energy, which not only cuts the cost, but also protects the environment. SBLDC Pump Controller can directly drive various kinds of 3-phase BLDC motor, with high power integration and less components, which improves the system reliability.
>>> More efficient, longer life, low power consumption.
>>> Based on the same volume of water, it requires lesser quantity of solar panel com-paring with AC pump ,user investment smaller, lower cost.
High speed digital signal processor DSP, high speed MPPT tracking, adapt to changeable weather.
>>> Protection: High-water protection, Low-water protection.
Product Parameters
solar controllerparameter
NK-SBLDC_48/1048V/10A,input Mppt DC voltage: 58-72v
NK-SBLDC_96/1096V/10A,input Mppt DC voltage: 96-144v
NK-SBLDC_96/2096V/10A,input Mppt DC voltage: 96-144v
NK-SBLDC_96/2096V/10A,input Mppt DC voltage: 96-144v
NK-SBLDC_220/15220V/15A,input Mppt DC voltage: 220-256v
solar pumpparameter
NK-WP0.375KW0.5HP/0.375KW; 2.7m³/40m,1m³/52
NK-WP0.75KW1HP/0.75KW;3m³/40m,1m³/52
NK-WP1KW1.3HP/1KW;2.4m³/40m,1.6m³/52
NK-WP1.5KW2HP/1.5KW;2.2m³/80m,2m³/98
NK-WP2KW2.7HP/2KW;2.5m³/120m,3m³/100
Product DescriptionSolar panel* 25 years Warranty
* Highest conversion efficiency of 17%
* Anti-reflective and anti-soiling surface power
* Excellent mechanical load resistance PID Resistant, High salt and ammonia resistanceSolar pumping inverter* Automatic MTTP function
* LCD+LED displayCold start functionPump* IP65 degree
* Dry run protection
* Lightning protection
* Remote controlMounting Structure10years quality warrantyKinds of raw material choice
Customization acceptable
Pitched, flat & workshop roof available
Our Project
Company ProfileAs a leader in solar power station, NAMKOO POWER is committed to building high-quality solar power station and setting up industry benchmarks, providing users quality services and safely Tailor-made engineering solutions as well as money for a long time. We provide systematic bank financing plan and full range of insurance for each customer to protect their income. NAMKOO POWER adheres to the goal of building a quality power station. Through global channels, technological means and continuous research and development innovation capabilities, NAMKOO POWER strives to make greater contributions to the development of global clean energy, the improvement of people's quality of life, and the construction of blue sky.
Packaging & Shipping
FAQ1. Are you manufacturer or trading company?
We are one-stop services manufacturer specialized in solar system over 15 years. Apart from it, we can also provide design & bills of solar system for our customers.
2. Can you customize the product?
Yes, as an experienced factory, ODM and OEM customization are acceptable as according to customer requirement.
3. What certifications do you have?
Our products are approved by CE, Rohs, SGS, SONCAP, VDE and etc.
4. What's the payment term?
T/T, L/C, Western union, trade assurance, cash. 30% for deposit and 70% balance before shipment.
5. How do you control the quality of your products?
There's no doubt that quality is very important. We carry out quality control with experienced professional QA and QC teams for each project.
