Ts-H3087xu-RP Network Attached Storage-USB Interface Best-in-Class HDD/SSD Hybrid Storage Solutions

Product Description

Product Description The high-capacity TS-h3087XU-RP is powered by the latest Intel® Xeon® E-2300 processors and DDR4 ECC memory (up to 128 GB) to deliver server-class performance without sacrificing system stability. HDD/SSD hybrid storage allows businesses to enjoy storage applications that balance performance and cost. The TS-h3087XU-RP features a built-in ZFS-based QuTS hero operating system that values data integrity, including real-time deduplication and compression, virtually unlimited snapshots, real-time SnapSync data synchronization, and data protection capabilities with QNAP SSD Antiwear Leveling. The ideal NAS choice for efficient enterprise backup and offsite redundancy. Specification Feature Specification

Model	TS-h3087XU-RP-E2378-64G
CPU	Intel® Xeon® E-2378, 8-core/16-thread, 2.6 GHz base frequency, up to 4.8 GHz with overclocking
CPU Architecture	64-bit x86
Graphics Processor	Optional PCIe adapter card
Floating-point Operation	-
Encryption Engine	AES-NI
System Memory	64 GB ECC DDR4 (2 x 32 GB)
Memory Upgrade Limit	128 GB (4 x 32 GB)
Memory Slots	4 x ECC UDIMM DDR4
Note on Memory Configuration	For dual DIMM configurations, identical DDR4 modules must be used in pairs.
Flash Memory	5 GB (Dual-boot OS protection)
Drive Bays	30 (24 x 3.5-inch SATA + 6 x 2.5-inch SATA)
Supported Drive Types	3.5-inch bays: 3.5-inch SATA HDD, 2.5-inch SATA SSD<br>2.5-inch bays: 2.5-inch SATA SSD
Hot Swappable	Supported
M.2 Slots	Expandable via optional QM2 PCIe adapter card
SSD Cache Acceleration	Supported
GPU Passthrough	Supported
2.5 Gigabit Ethernet Ports (2.5G/1G/100M)	2 (2.5G/1G/100M)
10 Gigabit Ethernet Ports	2 x 10GBASE-T (10G/5G/2.5G/1G/100M)
25 Gigabit Ethernet Ports	Expandable via optional PCIe adapter card
Wake on LAN (WOL)	Supported
PCIe Slots	3 (2 x Gen 4 x4 + 1 x Gen 4 x8)
Slot 1 Card Dimensions	260 x 131.15 x 54.16 mm / 10.24 x 5.16 x 2.13 inches
Slot 2 Card Dimensions	300 x 131.15 x 54.16 mm / 11.81 x 5.16 x 2.13 inches
Slot 3 Card Dimensions	300 x 131.15 x 18.76 mm / 11.81 x 5.16 x 0.74 inches
Note on PCIe Slots	Larger cards can be installed if the next PCIe slot is not used.
USB 3.2 Gen 2 Ports (10Gbps)	4 x Type-A USB 3.2 Gen 2 (5V/1A, 10Gbps)
HDMI™ Output	Optional via PCIe adapter card
Form Factor	4U Rackmount
LED Indicators	Status (Green/Red), Network (Green), USB (Blue), Drive status (Green/Red)
Buttons	Power, System reset
Dimensions (H x W x D)	176.2 × 441.6 × 630.2 mm
Weight (Net)	23.79 kg
Weight (Gross)	29.13 kg
Operating Temperature	0 - 40°C (32°F - 104°F)
Storage Temperature	-20 - 70°C (-4°F - 158°F)
Relative Humidity	5~95% RH (non-condensing), Wet bulb: 27˚C (80.6˚F)
Power Supply	800W (x2) Power supplies
Power Consumption (Disk Sleep Mode)	149.92 W
Power Consumption (Typical in Operation)	219.03 W
Fans	4 x 80mm, 12VDC
Standard Warranty	5 years
Maximum Concurrent CIFS Connections (with Maximum Memory)	11,000
