Full or Low Lift Spring Loaded Bronz Pressure Safety Relief Valve
| US$65.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
A48Y
Certification
CCC, ISO
Temperature
Ordinary Temperature
Closed
Open
Structure
Spring
Material
Stainless Steel
Characteristic
Safety Valve
Design & Manufacture
API 520, ISO 4126
Pre-Temp. Rating
ASME B16.34
Face to Face
API 526, En558 or DIN 3202
Ends Connection
NPT, RF, Rtj
Inspect & Test
API 527, DIN 3230 or ISO 5208
Certificate 1
Dnv CE 0575
Certificate 2
ISO 9001: 2008
Transport Package
Sea Worthy
Specification
API, ISO, BS, JIS, DIN, EN
Trademark
VATAC or OEM
Origin
China
HS Code
84818010
Production Capacity
8000ton per year
Product Description
Full or Low Lift Spring Loaded Safety Relief Valve with Open or Close Bonnet Conform to API 520, ISO 4126
They are tested according to API 527, and marked as per MSS SP-25
1. Construction is as follows
| - Full Lift or Low Lift | ||
| - For Steam | ||
| - Adjusting Set Pressure | ||
| - Closed Bonnet or Open Bonnet | ||
| - With or Without Lever | ||
| - Screwed Ends to ASME B1.20.1 | ||
| - Flanged Ends to ASME B16.5 |
2. Main Part & Materials
| Part Names | Part Materials | ||||||
| Body | WCB | LCB | WC6 | CF8 | CF8M | CF3 | CF3M |
| Bonnet | WCB | LCB | WC6 | CF8 | CF8M | CF3 | CF3M |
| Trim | 13%Cr/SS304 | SS304 | SS316 | SS304L | SS316L | ||
| Bolts/Nuts | B7/2H | L7/4 | B16/4 | B8/8 | B8M/8M | B8/8 | B8M/8M |
| Suitable Medium | Steam | ||||||
| Suitable Temperature | -29~425 °C | -46~340 °C | -46~340 °C | -196~427 °C | -196~427 °C | -196~427 °C | -196~427 °C |
3. Normal Pressure Rating
PN10~PN420, CLASS150~2500
4. Normal Size Range
DN15~DN600, 1/2"~24"
5. Pictures
Final Inspection
Shipment
