Stone Cutting Machine Automatic Hollow Brick Making Machine Production Line for Colombia

Product Description

Product Description
QT6-15 Automatic Concrete Cement Brick Block molding Machine QTF6-15 is a full automatic brick machine production line, its shape design is reasonable, the production efficiency is high. It have following features:1.Material and weldingAll material and spare parts selected according to international CE standard, Carbon dioxide protection will assure whole line stable running.2. Electric control systemWe selected original Mitsubishi PLC combine with independent machine control system to assure stable and high-efficiency working status.3.Switches and motorSwitched will use Japan Omron, motor will use Siemens or ABB band.4.Hydraulic systemThe machine adopting the advanced hydraulic molding technology, it can assure the block machine have stable and high-efficiency working status, and the blocks produced are of better quality,larger density and higher strength.5.Block mould Our block moulds are made of 16# manganese steel.Besides the good raw material, precise line cutting technology and 900ºC carburizing heat treatment technology are all adopted in the process of brick moulds production.Then the mould size error can be controlled within 0.002mm . The surface layer of the brick moulds get higher hardness (achieving HRC54-58) and better wear resistance.6. Vibration system
The machine adopts the special technology to optimize the vibration shaft, so that the proportion of vibration is covered in the whole surface range, so the product quality is greatly improved and the noise is effectively reduced. The machine's unique fixed platform design forms can improve the molding speed and dimensional accuracy.
Detailed Photos

The material feeding box guide rail is carburized and heat treated, which is more wear-resistant and has a long service life under high-frequency use.Material feeding arm adopts double bearing design, which is more efficient.
Automatic or semi-automatic operation,PLC controlled,easy to operate with high capacity,can produce hollow block,solid brick,colored pavers and curbstone.Domestic famous motor, use national standard Q345 steel and good welding.
The template is processed by precision machining, it is flat and durable, and has strong vibration force, so the bricks produced are smooth and flat. Mould change is easy to produce different types of block.
Product Parameters

SPECIFICATIONS FOR QTF6-15 CONCRETE BRICK MAKING MACHINE
Dimension of host machine	3500*1600*2830mm
Mould period	15S
Size of pallet	960x700x30mm
Weight of host machine	7.5T
Host machine power	29.7kw
Hydraulic pressure force	35.5KN
Mixer model	JS500

The block molds is customizable and replaceable to produce different kinds of blocks according to your requirement.
Installation Instructions

Company Profile
FULANG Machinery Group Co. Ltd is a Chinese manufacturer of dedicated machinery for construction blocks and panels. Our company offers complete production lines for premium building components such as the autoclaved sand -lime brick, autoclaved aerated concrete brick, and autoclaved aerated concern autoclaved lightweight concrete panel. Additional, we provide various types of pressure vessels and block-making machines. By choosing FULANG,customers can enjoy professional benefits with our dedicated services for design, install, layout planning, technology transfer,and production guidance.
With 20 years development , our products have been sold to more than 80 countries.Till now, about 1200 customers have visited our factory. Also we have engineers stay abroad to help you install the machines and training your workers at your side.
Packaging & Shipping

Related product

FAQ
Q: what is the material for this machine ?
A: crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes
Q: How many kinds of block can be made by this machine ?
A: this machine is able to make all types of hollow blocks, solid bricks, paving blocks, curbstone, hemp blocks, ceiling blocks, habiterra block etc. just need to exchange molds
Q: What is the hydraulic oil for this machine ?
A: Summber use 46#, winter use 32#. all easily found locally
Q: Will you provide spare parts for this machine ?
A: we will provide you one year free spare parts.can support machine working for many years
Q:Will you provide installation support?
A: we will provide installation video and manual book.online video avaiable also.
Q:How many days to receive the machine after place order?
A: 20-30days, depends on molds quantity.
Q: How about payment terms?
A: 30% down payment,. 70% balance before loading
Q: How about warranty?
A: 18months.
Q: How about installation?
A: We provide manual, guidance video and video call, if needed, we can also dispatch our engineer to your site to install, commission and train workers
