Jwell Small Automatic Blowing Molding Plastic Manufacturing Making Machinery Machine for Auto Parts, Automotive Parts and Plastic Boxes

Product Description

Product Parameters

Model	Unit	BM30
Max product volume	L	30
Dry cycle	Pc/h	600
Die head structure	type	Accumulating Type
Main screw diameter	mm	80
Max plasticizing capacity(PE)	kg/h	120
Driving motor	KW	37
Oil pump motor power(Servo)	KW	22
Clamping force	KN	280
Space between platen	mm	400-900
Platen size W*H	mm	740*740
Heating power of die head	KW	20
Machine dimension L*W*H	m	4.3*2.2*3.5
Machine weight	T	12
Total power	Kw	95

Detailed Photos

Product Description
Product Description:
The JWZ-BM30/50/100/160 Blow Molding Machine is an advanced solution for manufacturing a wide range of automotive parts and plastic boxes, offering superior precision, versatility, and efficiency.
Key Features: Wide Application Range: Suitable for producing car urea boxes, toolboxes, automotive seats, air ducts, flow boards, bumpers, and car spoilers, catering to the diverse needs of the automotive industry. High Output Extrusion System: Equipped with a high-performance extrusion system and accumulating die head for consistent and efficient production. Customizable Platen and Size: Adjustable platen type and size to accommodate various product dimensions and ensure production flexibility. Optional Hydraulic Servo Control System: Enhances energy efficiency, precision, and operational stability. Material-Specific Options: Features the JW-DB single-station hydraulic screen-exchanger system to handle different material requirements effectively. Optional Bottom Sealing and Take-Out Robot: Provides automation options such as bottom sealing and robotic product removal to reduce labor costs and improve production efficiency. Applications: Car urea boxes for emission reduction systems. Toolboxes for automotive and industrial use. Plastic bumpers, air ducts, and flow boards for lightweight automotive components. Custom car spoilers and other plastic automotive parts designed for durability and performance. This blow molding machine offers a highly efficient and customizable production process, tailored to meet the demands of the automotive and industrial sectors for plastic parts and boxes with exceptional quality and reduced production costs.
