Small Asphalt Concrete Mixing Equipment, Integrated, Digital, Modular Design
| US$10,000.00-150,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
LB-1000
Application
Road Engineering
Application Area
Engineering & Construction
Certification
Shqc, Lqa
Condition
New
Control System
PLC Control
Cooling Method
Air Cooling
Heating Method
Thermal Oil Heating
Main Material
Alloy Steel, Carbon Steel, Cast Iron, Stainless Steel
Mixing Capacity
1000kg
Safety Features
Emergency Stop Button, Overload Protection, Safety Lock
Speed Control
Fully Automatic Control
Speed Range
Fully Automatic Control
Stirring Type
Rotary Convection Extrusion Type
Temperature Control
Heating and Cooling Systems
Working
Rotary Convection Extrusion Type
Rated Productivity(T/H)
60-80
Mixing Tank Capacity(Kg/Batch)
1000
Consumption Rate (Kg/T)
<=6.5
Typr So Fuel
Disesl Oil, Heavy Oil, Naturl Gas
Product Temperature (ºC)
140-160
Aggregate Measurement Accuracy (%)
<=0.3
Asphalt Material Measurement Accuracy (%
<=0.1
Powder Measurement Accuracy (%)
<=0.2
Oil Stone Ratio Deviation (%)
<=0.1
Ambient Noise [dB(a)]
<=80
Operator Ear Noise [dB(a)]
<=70
Dust Removal Method
Compartment Splitting, High-Pressure Pulse Bag
Dust Emission Concentration [Mg/Nm3]
<=100
Transport Package
Container
Specification
35*30=1050
Trademark
Taite
Origin
China
HS Code
8474310000
Product Description
Product introduction:Compact overall layout, novel structure, independent innovation and absorption of international advanced technology, excellent performance.
Advanced microcomputer control system, PLC module can achieve automatic, semi-automatic, manual joint control and single control. Simulation screen real-time dynamic display, full range of fault self-diagnosis.
The whole machine adopts electronic measurement. The advanced double-stroke measuring method has automatic compensation function and high measuring accuracy.
Unique environmental performance, fully sealed, low noise, dust emission standards.
The core components are assembled with imported components to fully ensure the reliability of the entire equipment.
The production capacity is 160 tons per hour.
THE MAIN TECHNICAL CHARACTERISTICS:
| content/type | LB-1000 |
| Rated productivity(t/h) | 60-80 |
| Mixing bar capacity(kg/batch) | 1000 |
| Total installed capacity (Finished product warehouse is not included)(kw) | 260 |
| Total floor area(m×m) | 35×30=1050 |
| Fuel consumption rate(kg/t) | ≤6.5 |
| Type of fuel | diesel fuel,heavy oil,natural gas |
| Finished material temperature(ºC) | 140-160 |
| Cumulative measurement accuracy of ore materials(%) | ≤±0.3 |
| Measurement accuracy of asphalt materials(%) | ≤±0.1 |
| Powder metering accuracy(%) | ≤±0.2 |
| Oil-stone ratio deviation(%) | ≤±0.1 |
| Stable and accurate discharge temperature(ºC) | ±5 |
| Ambient noise[dB(A)] | ≤80 |
| Noise in the operator's ears [dB(A)] | ≤70 |
| Dust removal method | Compartment, high-pressure pulse bag |
| Dust emission concentration[mg/Nm3] | ≤100 |
