RS232 to RS485 RS422 Adapter Converter Female dB9 Pin Seriel Port

Product Description

RS232 Serial to RS485 RS422 Converter
Mini RS-232 to RS485 422 Converter
RS-232 Serial to RS-485 Converter
RS-232 Serial to RS-422 Converter
RS422 RS485 Interface Converter

The adapter adopts two locking methods : front rivet nuts and rear locking screws, can be switched at will.
Specification :
DWG : PCM-KW-474
Input Signal : RS232 Serial
Output Signal : RS485 RS422
Input Connector : DB9 Male
Output Connector : 5 Pin Terminal Block, 3.81 Pitch
The RS232 to RS422 RS485 product is a serial port converter, used to connect RS232 serial port devices and RS422 or RS485 serial port devices for communication. Convert an RS-422 or RS-485 DB9 RS232 serial connector to a terminal block connector, these products are widely used in industrial control, Internet of Things, remote monitoring and other fields, and can realize interconnection and interoperability between different types of serial devices.
Product function introduction:
1. Signal conversion: Convert the signal sent by the RS232 serial port device into a signal format acceptable by the RS422 or RS485 serial port device to achieve communication interconnection between different types of devices.
2. Level conversion: Convert the level signal of RS232 serial port device into a level signal suitable for RS422 or RS485 serial port device to ensure the stability and reliability of signal transmission.
3. Data transmission: realizes two-way transmission of data between RS232, RS422 and RS485, supporting the reliability and stability of data communication.
4. Communication protocol compatibility: Supports different communication protocols such as RS232, RS422 and RS485 to ensure compatibility with various serial devices.
5. Industrial-grade design: It has industrial-grade design and reliability, and is suitable for long-term stable operation in industrial automation, control systems and other environments.
Usage:
1. Industrial automation:
Connect RS422/RS485 devices such as industrial equipment, sensors, and PLCs to exchange data with RS232 controllers or computers to achieve industrial automation control and monitoring.
2. Remote monitoring:
In the remote monitoring system, the RS422/RS485 signals of remote sensors or monitoring equipment are converted into RS232 signals to communicate with the monitoring center or computer.
3. Building automation: Connect RS422/RS485 devices such as controllers and sensors in the building automation system with the central controller or computer for data exchange and control.
4. Internet of Things applications:
Connect different types of Internet of Things devices to achieve data communication and integration between RS232 serial devices and RS422/RS485 devices.
5. Long-distance data transmission:
Utilize the long-distance transmission characteristics of RS485 to transmit data from RS232 devices to remote RS485 devices, which is suitable for long-distance data transmission scenarios.
