3 Axis Vmc600 Mini CNC Milling Machine Machine Centre CNC Vertical Machining Center High Quality CNC Milling Machining Center
Basic Info.
Model NO.
vmc600
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Movement Method
Linear Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.04~0.05(mm)
Performance Classification
High-End CNC Machine Tools
Certification
CE
Condition
New
Machining Center
CNC Machining Center
Machining Center CNC
CNC Machine Center
Machine Center
Machine Center CNC
Milling Machine
CNC Milling Machine
Spindle Taper
Bt40-120
X/Y/Z Axis Rapid Feed
24/24/16 M/Min
Transport Package
Packing in Seaworthy Wooden Cases
Specification
Dimension(L*W*H): 2600*1950*2400mm
Trademark
DRC
Origin
China
Production Capacity
500
Product Description
cnc milling machine model VMC cnc milling machine body 850 cnc milling machine modelCNC vertical machine center vmc cnc milling machining center with high quality for metal work DRC machining center is suitable
for processing machinery and mold manufacturing field of vertical machining center, from the rough machining and finish machining
and processing requirements apply, can finish milling, drilling, tapping, boring, and a variety of processes. Vertical machining center
fearturs : 1.High quality resin sand 2. Japanese NSK bearing 3. Twaiwan spindle 4. Germany R+W coupling 5. Taiwan ball screw
and locking nut 6. Automatic lubrication system 7. Taiwan pressure cylinder 8. Chip conveyor at optional
| Model | VMC 600 | VMC640 | VMC650 |
| Travel parameters of 3 axis | |||
| X /Y/Zaxis travel | 500/320/450mm | 600/400/450mm | 650/450/500mm |
| Spindle face to table distance | 70-520mm | 80-530mm | 100-600mm |
| Distance between spindle center and column guide surface | 360mm | 400mm | 500mm |
| Worktable parameters | |||
| Worktable size | 800×260mm | 800×320mm | 900×400mm |
| Maximum load bearing of worktable | 400kg | 400kg | 450kg |
| T Shot | 3×16×75mm | 3×16×100mm | 5×16×75mm |
| Feeding parameters | |||
| X/Y/Z axis rapid movement rate | 24/24/16 m/min | 24/24/16 m/min | 24/24/16 m/min |
| Feed moving velocity X, Y, Z | 1-10m/min | 1-10m/min | 1-10m/min |
| Spindle parameters | |||
| Main shaft connection | Belt | Belt | Belt |
| Spindle taper | BT40-120 | BT40-120 | BT40-120 |
| Range of spindle speed | 8000rpm | 8000rpm | 8000rpm |
| Spindle motor power | 5.5kW(Alternating current servo) | 5.5KW (Alternating current servo) | 5.5kW(Alternating current servo) |
| ATC paremeters | |||
| ATC capacity | 12qty | 16qty | 16qty |
| Maximum tool size | Φ92mm(tool from a distance) | Φ92mm(tool from a distance) | Φ92mm(tool from a distance) |
| Maximum tool weight | 5kg | 5kg | 5kg |
| Precision | |||
| PositionaI accuracy(JIS standard) | ±0.008/300mm | ±0.008/300mm | ±0.008/300mm |
| Repeated positioning accuracy(JIS standard) | ±0.005mm | ±0.005mm | ±0.005mm |
| Shape and weight | |||
| Machine size | 2200×2100×2260mm | 2600×1950×2400mm | 2500×2100×2360mm |
| Weight | 2400kg | 2600kg | 3800kg |
