Hot Sale Energy Saving Well-Sealed Rubber Kneader Internal Mixer Machine

Product Description

Product Description Rubber & Plastic Dispersion Mixer/Rubber Kneader Machine principle
putting discarded tires on fork and rising it to a fixed location by hydraulic system ,then cutting the tires by upper moveable dividing the discarded tires, plastic,metal and other materials.
Machine Advantages
1. Maximum Dispersion & High Production
Double blades with special spiral angle, proper clearance and high cooling effect give excellent dispersion which can not be obtained from open mill. Its production is 4 to 5 times more than an ordinary mixing mill thus saving on labor and electricity. 2. No Powder LeakageBoth sides of the rotor blades are injected welding a iron alloy ring, which assures sealing and protects the blades from abrasion. Imported bakelite sealing ring, which make super sealing. The chamber around are designed with groove, then embeded with rubber stip, this make sure the whole mixing chamber is well sealed. 3. No Foundation Requirement
The machine has a common bed plate for all parts and not require foundation.
4. Easy Cleaning & Color Change
Mixing chamber can be tilted down for 140 degree, which enables easy cleaning, because of this, different coloured compounds can be made without trouble.
5. Easy Operation
Easy operation with Push-buttons and hand lever valves from the operation board. 6. Short Mixing Time
Mixing time ranges from 6 to 12 minutes depending on compound's specific gravity.
technique parameter

Parameter name	X(S)N-35/30	X(S)N-55/30	X(S)N-75/30
The total volume of the mixing chamber (L)	75	55	75
The total volume of the mixing chamber mixer(L)	35	55	75
The ratio of Before and after of Rotor speed (RMP)	30/24.5	30/24.5	30/24.5
The main motor power (KW)	55	75	110
The main motor speed (RMP)	980	980	990
Dimension of the external form(length*width*height)(mm)	3200*1900*2945	3750*1950*3550	3325*2600*3200

Our Services Factory Acceptance Testing before Delivery
Guarantee time: One year
Other Service Articles:
1.We grant one more set of Oil-seals,
2.We can provide the engineer testing and commonisioning overseas .
3.We can send workers to guide (at uyer's cost for the plane ticket and accommodation)
Packaging & Shipping
Company Information Qingdao Evertech Industry Co., Ltd We are the sister company with Taixing Reshine Rubber&Plastic Machinery Co., Ltd ,Ningbo Dechuan Machinery Co., Ltd and Wuxi Zhenxing Machine Co.,having more than 10 years of experience in the field of rubber&plastic machineries, owning 5 manufacturing plants, mostly are located within the scope of 300 KM around Shanghai, having dozens of experienced engineers and more than 100 skilled workers, as well as a considerable number of precise, digital-control, advanced processing machine tools. All ensure every part and details of our machines with good performance and qualified running test before delivery to our customers on time.
Our main products include: Dispersion Kneader,Banbury Mixer,Two Roll Open Mixing Mill,Rubber Precision Preformer (Barwell),Rubber Calender,Hydraulic Vulcanzing Press,Rubber Extruder,Rubber Filtering Machine,Single Screw Extruder and Twin Screw Extruder for Compound Pelletizing,Sigma Kneader,Bandknife Splitting Machine for EVA/PE/EPDM/CR/RUBER CORK,Rubber Crusher Mill and Rubber Refining Mill for Reclaimed Rubber,Rubber Cutting Machine,Cooling Machine,etc.
FAQ
1.What are the payment terms?
TT,L/C and trade assurance are acceptable,TT will be more appreciated,30% deposit before production,70% balance before shipment.
2.What is the delivery time?
At least 1 month after the deposit recipit,depend on how many machines included in the line.
3.How to pack the machine?
Standard packaging
4.How to install after the machines arriving destination?
Our engineer will go to customers site if you need,but need to pay installation fee accord with the contract.
5.What's the capacity you can do?
We always produce depend on customers' requirement. Welcome to send me email any time.
Contact :Victoria Zhang
