90HP Rubber Tractor Crawler Tractors for Agriculture Tractor Truck with 2.3m Cultivator

Product Description

50-100HP Farm Tractor,Rubber Tractor,Crawler Tractor



Product Description 1.Farm tractors engine form adopt renowned directly injection vertical water cooled 4-stroke(In line,EFI,water cooled,4-stroke) YTO/CHANGCHAI engine.
2.Agricultural equipment tractors Walking rubber track pitch section*number*width: 90*46*300(W602,60HP) 90*46*350(W502,50HP) 90*50*350(W702/802,70/80HP) 90*51*350(W702,70HP) 90*54*400(W802/902,80/90HP) 90*56*500(W902/1002,90/100HP)
3.China best selling tractors cltuch:single-plate, single-acting, wet friction clutch Type.
4.Our farm tractors Minimum ground clearance(mm):260,400,410,530,610.
5.Equipment farming tractors of gear box:F12+R12;F8+R8;2(machanical gear)+2*2(hydraulic stepless speed change);Main transmission(hydraulic stepless speed change+machanical gear)+2(secondary speed change).
6.PTO:φ38,8teeth φ38,6teeth,Speed:720/1000.Linkage:II Rear Mount 3-point Linkage. We can produce and customize all sorts of medium-sized tractor 50 HP - 100 HP farm crawler tractors, diesel type, electric type can be customized production, and the tractor with all series farm implements, such as ridging machine,rotary tiller,disc plough, flattener,ditching machine,windrower,harrow, loader, backhoe, trailer,mower,grass chopper,silage corn straw harvester,small excavators etc you want. But firstly, tell us your preferred horsepower tractor.

Product name	Rubber Tractor ,Crawler Tractor W-902
Minimum ground clearance (mm)	400
Engine	Mode	YD4EZ90C1
	Form	direct injection ,vertical,water cooled,four-stroke
	Rated power(kW)	66.2
	Fuel	diesel fuel
	Rated speed r/min	2400
	Starting method	electric start
Steering brake system	Steering System Type	planetary differential steering
	Brake system type	wet friction type
Drive train	Clutch type	single - chip single - acting
	Transmission type	8 eight forward speed+reverse gear
	Transmission shift mode	gear shift
Walking system	Rack form	rigid frame type
	Track Pitch section × number × width	90×54×400
	The theoretical speed of each file(km/h)	go ahead 1.22;1.80;2.92; 3.84;5.50;8.08;13.13;17.25 Backward:0.97;1.43;2.32;3.04;4.36;6.41;10.42;13.68
Working device	Lifter type	semi-Split
	Tillage depth control	force adjustment
	PTO form	type1, non-independent
	Power output shaft speed(r/min)	720/1000
	PTO shaft spline and the outer diameter mm	8×38
