Konecranes 630kg Electric Chain Hoist with Trolley for Workshop or Warehouse Handling

Product Description

Konecranes Electric Chain Hoist with Trolley
The Konecranes C-series chain hoist is the new generation of electric hoists of Konecranes and also a flagship product.
Product Description
Design and Structure Compact and Lightweight: It is compact in design, occupying little space, which is convenient for installation and operation. The universal bracket design is conducive to quick and safe installation, and there are various hanging methods. The core components are of high quality. The gears are lubrication-free for life, and the motor is specially designed for lifting.
Performance Wide Lifting Capacity Range: Ranging from 63 kg to 5000 kg, it can meet the lifting requirements of different scales. There are various lifting speeds, with double-speed or frequency conversion control. The duty cycle can reach 60%, enabling continuous operation. It can work within the temperature range of -20°C to +40°C, and can reach even higher temperatures under special configurations.

Safety Assurance Reliable Braking System: It is equipped with a self-adjusting brake that can quickly stop in emergency situations. There are also a friction clutch for overload protection and limit switches to ensure safety.
Operation and Control Convenient Operation: The operation is simple and it can be controlled by a pendant control or a remote control. The hook is ergonomically designed with an anti-slip coating.
Detailed Photos


Product Parameters

Lifting Weight	Model	working level Fem/Iso	Lifting speed m/min	number of chains 1/2/4
125kg	C02 P 08 1 012 6	3m/M6	8/2	1
160kg	C02 P 08 1 016 6	3m/M6	8/2	1
250kg	C02 P 08 1 025 5	2m/M5	8/2	1
320kg	C05 P 08 1 032 5	2m/M5	8/2	1
500kg	C05 P 08 1 050 5	2m/M5	8/2	1
630kg	C10 P 08 1 063 6	3m/M6	8/2	1
1000kg	C10 P 04 1 100 5	2m/M5	4/1	1
1250kg	C10 P 04 1 125 4	1Am/M4	4/1	1
1600kg	C10 P 04 2 160 5	2m/M5	4/1	2
2000kg	C10 P 04 2 200 5	2m/M5	4/1	2
2500kg	C10 P 04 2 250 4	1Am/M4	4/1	2
3200kg	CLX16 04 2 320 5	2m/M5	4/0.7	2
4000kg	CLX25 04 2 400 6	3m/M6	4/0.7	2
5000kg	CLX25 04 2 500 5	2m/M5	4/0.7	2
6300kg	CLX25 03 3 630 4	1Am/M4	2.7/0.4	3
7500kg	CLX25 03 3 750 4	1Am/M4	2.7/0.4	3
10000kg	CLX25 04 4 10T 4	1Am/M4	4/0.7	4

If there is a demand, please inform us of the following data. We will select a suitable model for you according to the actual working conditions.

Lifting Weight kg
Lifting Height m
Lifting Speed m/min	Are there any special requirements?
Voltage v
Other Requirements
Trolley Type	Manual/Electric
