Agriculture Machinery Matching Beach Vehicle and ATV Track System Yk-220

Product Description

Specifications
1). Continuous rubber track
2). Conventional type or interchangeable type rubber track
3). Warranty: guarantee one year

The Rubber Track System/Track Kits are made of high-tech material,could be used on Wheelchair,Military field operation,Anti-terrorist,Patrol,Oil search etc.They could walk on all terrain and all unusual environment like Snow,Swamp,Desert,Gobi,Mountain and so on.They are easy and quick interchange with the tyre,no need change anything about the vehicle.

Model:	YK-220	Length:	710mm
Packing:	Simple/Cardboard Box/Iron Frame	Width:	220mm
Material:	Steel Rubber Polymer	Height:	420mm
Ground Contact Length:	480mm	Net Weight:	53.6kg
Sprocket Center Distance to the Ground:	300mm	Load bearing:	350kg
Links for Rubber Track:		19
Applicable Type of Vehicles:		Agricultural,agricultural machinery matching,beach vehicle
Model:	FJBM-220	Length:	680mm
Packing:	Simple/Cardboard Box/Iron Frame	Width:	220mm
Material:	Steel Rubber Polymer	Height:	440mm
Ground Contact Length:	440mm	Net Weight:	60.47kg
Sprocket Center Distance to the Ground:	305mm	Load bearing:	350kg
Links for Rubber Track:		19
Applicable Type of Vehicles:		Agricultural,agricultural machinery matching,beach vehicle

1. Type of rubber tracks:
(1) Bolt on type
(2) Bolt on type with steel bottom
(3) Chain on type
(4) Clip on type
(5) Pavers rubber pads


1 The feature of rubber tracks:
(1). Less round damage
Rubber tracks cause less damage to roads than steel tracks, and less rutting of soft ground than either steel tracks of wheel products.

(2). Low noise
A benefit to equipment operating in congested areas, rubber track products less noise than steel tracks.

(3). High speed
Rubber track permit machines to travel at a higher speed than steel tracks.

(4). Less vibration
Rubber tracks insulate machine and operator from vibration, extending the machine's lifetime and lowering operate fatigue.

(5). Low ground pressure
The ground pressure of rubber tracks equipped machinery can be fairly low, about 0.14-2.30 kg/ cmm , a major reason for its use on the wet and soft terrain .

(6). Superior traction
The added traction of rubber, track vehicles permits them to pull twice the load of wheel vehicles of the sane weight.

2. Application:
For small robot, wheelchair, mini excavator, off-road jeep,sand-beach vehicle, snowmobile,snowblower, bulldozer, agriculture, combine harvester machine,rice harvester machine,wheat harvester machine,bulldozer,dumper,crasler loader,crawler crane,carrier vehicle,swamp truck,amphibious tank,etc

3.Warranty:
Guarantee one year under normal use.

4,Specification:
Wide range track size is available for your kind choosing.Please kindly send us email for details.
