Handheld Fiber Laser Welding Machine 2000W
Basic Info.
Model NO.
HW-2000W
Application
Biomedicine, Electronic Industry, Automotive Industry, Manufacturing Industry
Technical Class
Continuous Wave Laser
Control
Manual
Power Density
Deep Fusion Welding
Laser Classification
Optical Fiber Laser
Type
Optical Fiber Transmission Laser Welding Machine
Color
Customized
Power
2000W
Transport Package
Carton
Specification
900x670x975mm
Trademark
OEM
Origin
Shenzhen, China (Mainland)
HS Code
8515390000
Production Capacity
10, 00 PCS/Month
Packaging & Delivery
Package Size
105.00cm * 72.00cm * 98.00cm
Package Gross Weight
200.000kg
Product Description
Product DescriptionOur Advantages
| Item | Traditional Welding | Last Generation Laser | Our New Generation Laser Welding |
| Heat Input | Very High | Low | Low |
| Workpiece Deformation Undercut | Big | Small | Small |
| Bonding Strength to Base Material | Normal | Normal | Good |
| Process after Welding | Polishing | No Need Less Polishing | No Need Less Polishing |
| Welding Speed | Normal | More Than TIG Welding | More Than Double TIG Welding |
| Suitable Materials | Stainless Steel Carbon Steel Galvanized Sheet | Stainless Steel Carbon Steel Galvanized Sheet | Stainless Steel Carbon Steel Galvanized Sheet |
| Consumables | More | Less | Less |
| Operation Difficulty | Complicated | Normal | Easy |
| Operator Safety | Not Safe | Safe | Safe |
| Environmental Protection | Not Environmental Friendly | Environment Friendly | Environment Friendly |
| Oscillating Welding | None | None | None |
| Spot Width Adjustment | None | None | None |
| Welding Quality | Bad | Normal | Good |
Product Parameters
| Item | Parameter | |
| Model | 1500 | 2000 |
| Item Name | Handheld Fiber Laser Welding Machine | Handheld Fiber Laser Welding Machine |
| Laser Power | 1500w | 2000w |
| Laser Wave Length | 1070nm | 1070nm |
| Fiber Length | 10/15m | 10/15m |
| Working Way | Continuously/Modulation | Continuously/Modulation |
| Welding Speed Range | 0-120 mm/s | 0-120 mm/s |
| Colling System | Industrial Thermostatic Water Tank | Industrial Thermostatic Water Tank |
| Protection Gas | Argon&Nitrogen | Argon&Nitrogen |
| Air Pressure | Welding>3bar Cutting>4-7bar | Welding>3bar Cutting>4-7bar |
| Working Environment Temperature | 15-35°C | 15-35°C |
| Working Environment Humidity | <70% No Dewing | <70% No Dewing |
| Recommended Thickness | 0.5-3mm | 0.5-5mm |
| Welding Gap | ≤0.5mm | ≤0.5mm |
| Voltage | AC220V | AC220V |
| Weight | 168kg | 200kg |
| Measurement | 900*670*975mm | 1050*720*975mm |
