Precision Vertical Knee-Type Milling Machine for Metal Fabrication

Product Description

Products Description Brief Introduction The vertical knee type milling machine is suitable for processing plane, inclined plane, groove and hole of various parts. It is an ideal processing equipment for machinery manufacturing, mold, instrument, instrument, automobile, motorcycle and other industries Features: Rectangualar table guideways with high stability Hardened and ground table surface, guideways Automatic feeds on X,Y axes, motorized lifting and lowering of table on Z axis. Headstock swivels ±45° 1.It is a vertical milling machine,high power 2.Processing range widely 3.Automatic feed on two axis ,motorized lift on Z axis. 4.Rectangular guideway,hardened treatment 5.The rigidity of yhe spindle,strong cutting force. 6.Equipped with manual lubricating device, the lubrication on the lead screw and guideway. Specifcation

Model		HUM32A x 16
Table size	mm	320 x 1600
Longitudinal travel X	mm	1024/1000
Cross travel Y	mm	300/280
Vertical travel Z	mm	410/400
Feed speed steps		18
Feed speed ranges: Longitudinal X	mm/min	15-750
Cross Y	mm/min	15-750
Vertical Z	mm/min	5.7-280
Min. distance between spindle center to table	mm	235-535
Spindle speed steps		18
Spindle speed ranges	kW	30-1500
Main motor power	kW	7.5
Overall size	cm	232 x 202 x 209
Net weight	kg	3350

Company Profile SJR Machinery Co., Ltd. , was founded in 1984, which is the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation. Our company specializes in the manufacture and import/export of brand new industrial machinery and tools. We are capable of producing more than 80 types of machines.Sincerely welcoming you to contact us for more information, we look forward to becoming your supplier in the near future. Order Evaluation Exhibition Customer Photos Certifications FAQ 1. How can I choose the most suitable machines ? A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you . 2. What is your payment terms ? A: 30% down-payment after contract ,and 70% payment before shipment, Meanwhite it can be discussed according to your situation. 3: Where is our factory located? How can I visit there? A : Our factory is located in No. 52 Linyin Road, Economic and Technological Development Zone, Nantong City, Jiangsu Province ,226001 China. You are warmly welcomed to visit us. 4. What is your delivery time ? The delivery depends on different machines with different configurations. Please contact us to confirm it is in stock or not. 5. Can you send the service engineer to our company ? We have engineers stationed in Canada, Egypt, and Algeria. The after-sales service system is very perfect. Vertical Knee-type Milling Machine metal milling machine
