Small Economical Type CNC External Cylindrical Grinder Machine

Small Economical Type CNC External Cylindrical Grinder Machine

US$1,000.00-15,000.00 1 set (MOQ)

Basic Info.

Model NO.
GKE-80*300
Abrasives
Grinding Wheel
Controlling Mode
CNC
Automatic Grade
Automatic
Cylindrical Grinder Type
Universal Cylindrical Grinder
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Color
According to Customers′ Require
Max. Grinding Diameter of Workpiece
80mm
Max. Grinding Length of Workpiece
300mm
Max. Workpiece Weight
10kg
Wheel Peripheral Velocity
35m/S
Wheel Spindle Speed
2800rpm
Wheel Size
250*25*75mm
Roundness/Roughness
1.5um/Ra0.32um
Total Power
3.4kw
CNC System
Beijing Knd1000ti
Transport Package
Wooden Pallet or Wood Case
Specification
CE ISO9001
Trademark
TIMAC
Origin
China(Mainland)
HS Code
8460211000
Production Capacity
500 Sets/Year

Product Description

Small Economical Type CNC External Cylindrical Grinder Machine
GKE-80*300

Main Functions and Features:
1. The machine structure is flexible, accuracy stability, high grinding efficiency, especially for less than 20mm culindrical or conical cylindrical workpieces, with delicate and simple features.
2. The electrical system is controlled by KND 1000Ti, other systems can also be configured according to the customer.
3. X-axis, Z-axis guide is using cross rolling linear guide, improve the sensitivity and minimum feed micro feed.
4. Wheelhead spindle is supported by three bushing hydro-dynamic bearing.
5. The machine can be equipped with radial and axial measurement instrument.

Main Accessories:
*Wheel periphery dresser
*Wheel hub
*Balancing arbor
*Open-type steady rest
*Wheel extractor
*Magnetic separator
Extra Accessories:
*Wheel balancing stand
*Diameter measuring instrument
*Specifications List

Technical Parameters

Specifications
Units GKE-80*300
Dia. to be ground mm Φ2-Φ80
Max. length to be ground mm 300
Center height mm 115
Distance between centers mm 300
Headstock center Morse 3#
Tailstock center Morse 3#
Max. workpiece weight to be ground kg 10
Wheel size mm Φ250*25*Φ75
Wheel peripheral speed m/s 35
Wheel spindle rptation speed rpm 2800
Min. pulse amount in X-axis mm 0.001
Min. pulse amount in Z-axis mm 0.001
Roundness um 1.5
Dia. uniformity in the longitudinal section um 5
Diameter measuring instrument um Ra0.32
Total motor power kw 3.4
Longitudinal servo motor power kw 1(3.3N.m)
Transverse servo motor power kw 1(3.3N.m)

**The foundation depth depends upon the soilproperties, but it should be less than 400mm. Our Advantages
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Packaging & Shipping
Company Profile
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
Customer visited
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
The following is one of the most satisfactory products recommended by customers, as well as our main product categories. you can click and view

Conventional Lathe CNC Lathe
CNC Machining Center
CNC Milling Machine
Grinding Machine Milling Machine
Special Use Lathe Boring Machine

FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
