Taijia Concrete Testing Gauge,rebar test meter,Ultrasonic Rebar Detector

Product Description

Product Description
GW50+ Rebar Location Detector Concrete Reinforcement Position Tester Introduction of GW-50 rebar locatorGW-50 rebar locator is non-destructive measurement of concrete cover and rebar diameters ,anddetect rebar locations . it using an electromagnetic induction method . It also can be used to testthe distribution of magnetic and conductor such as cables and metal pipes in non-magnetic medium and non-conducting medium Features of GW-50 rebar locator1.Maximum cover depth is 180mm2.Single comprehensive probe. No need to replace during test.3.Back-lit screen let instrument can be normal used under the condition of insufficient light4.Machine software is complete .The report could be printed automatically connecting with computer GW-50 rebar locator technical informationDiameter measuring rangeDiameter 6mm~50mmDiameter measuring accuracy±1rebar standardCover measuring rangeFirst rangeSecond rangeOperating temperature-10°C ~40°C6~907~180Power supplysix LR 6 (AA) batteriesCover measuring accuracy±1 mm6~597~79Battery Lifetime1.5 V for up to30 h±2 mm60~6980~119Humidity< 90%±4 mm70~90120~180Weight1.6 Kg
