1000kg/H Waste Plastic HDPE PE PP Rigid Bottle Crushing Washing Dewatering Recycling Line

1000kg/H Waste Plastic HDPE PE PP Rigid Bottle Crushing Washing Dewatering Recycling Line

US$20,000.00
1 Set
US$15,000.00
2 Sets
US$10,000.00
3+ Sets

Basic Info.

Model NO.
Gangsu PE Machine
Material Processed
Plastic Bottle
Plastic Type
PP
Screw
Double-Screw
Automation
Automation
Computerized
Computerized
Certification
QS, GMP, ISO9001:2008, CE
Blade Material
SKD-11
Usage
Shredding Crushing Washing Drying
Motor Brand
Siemens
Final Products Water Content
<5%
Exporting Countries
Worldwide
Transport Package
Wooden Box
Specification
1000kg/h PE
Trademark
GANGSU
Origin
China
HS Code
8477209000
Production Capacity
5000 Set/Year

Product Description


Our specialized HDPE PP recycling line is designed for reprocessing and cleaning HDPE bottles, pails, barrels, and PP pipes. The process includes bale opening, crushing, continuous washing, and drying using friction washing and a dewatering dryer.The final flakes, with less than 1% humidity, can be directly used in our plastic granulator to make pellets. Our automated HDPE PP rigid recycling equipment, ranging from 1000kg/h to 3000kg/h capacity, minimizes labor costs.
Material available for processing
Product Parameters
Capacity(kg/h) Power(kw) Size(m2) People Steam(kg/h) Air(m3/min) Water(m3/h)
500 220 400 8 350 4 1
1000 500 750 10 500 10 3
2000 700 1000 12 800 15 5
3000 900 1500 12 1000 15 6
4500 1000 2200 16 1300 18 8
6000 1200 2500 16 1800 18 10

Recycling Process
Product Description
Belt conveyor:
It mainly used for material conveying. It includes bracket, conveyor belt and motor. The conveyor belt is made of PVC , and there are universal wheels at the bottom of the bracket.
Crusher:
It is mainly composed of feed port, crushing chamber, screen mesh, discharge port and motor. After the material enters the crushing chamber, it is cut and torn by the rotating knife and fixed knife driven by the motor. The material that meets the sieve aperture will be discharged from the outlet port.

Screw feeder This equipment is used to transport the rinsed material to the rear equipment
Floating tank It is used to rinse the material for the first time to separate the sediment impurities in the material
Screw feeder This equipment is used to transport the rinsed material to the rear equipment
Moisture removal/drying systems Materials dewatered via squeeze dryers or dewatering machines. We'll assess your needs and guide in selecting the suitable method.
Zig Zag Drying System
It includes oven, fan and stainless steel pipe. The heated hot air is blown into the pipe to further dry the material.
Silo For storage of clean and dry plastic film flaks

Control cabinet For controlling the washing line and observing the operation of each piece of machine
