Professional Plumbing Manufacturer Pex B Pipe Pex Al Pex Piping for Underfloor Heating

Product Description

Product Description
Basic details
Origin: Hebei China Brand name: Transferable
Model: 16mm-32mm Material: Polyethylene
Specifications: 16mm-32mm Length: 50 meters or as needed
Thickness: 2mm to 4mm Standard: International Organization for Standardization
Processing Services: Forming, OEM Color: White gray or as needed
Type: Overlap and butt welding Sample: Free
Warranty: 50 years Minimum order quantity: 20000 meters
Product Details
This PEX AL PEX pipeline is used to produce 5-layer composite aluminum plastic pipes, with PEX material+adhesive material+aluminum material+adhesive material+PEX material. This PEX AL PEX pipe is mainly used in underfloor heating systems, hot water transportation, etc
Size chart

product	Size(mm)	Outer diameter(mm)	Tolerance(mm)	Thickness (mm)	Tolerance (mm)
Butt weldingPEX-AL-PEX	16*2.0	16	+0.3	2.0	+0.2
	20*2.0	20	+0.3	2.0	+0.2
	26*3.0	26	+0.3	3.0	+0.2
Overlap weldingPEX-AL-PEX	16*2.0	16	+0.3	2.0	+0.2
	20*2.0	20	+0.3	2.0	+0.2
	26*3.0	26	+0.3	3.0	+0.2
Other dimensions requested by the customer

Product advantage

High temperature resistance
The maximum continuous working temperature can reach 70 degrees Celsius, and the maximum transient temperature can reach 95 degrees Celsius.
Corrosion resistance
Resistance to chemical or electronic corrosion.
Reduce installation costs
Lightweight and easy to install, the installation cost can be reduced by up to 50% compared to metal pipeline systems. Product application

• Distribution of hot and cold water pipelines, residential and commercia
Radiation heating and cooling system (floor, wall, ceiling)
• Hydraulic piping and distribution (radiators, fan coils, etc.)
• Lawn regulation/court heating
Outdoor snow and ice melting system
• Chilled water pipeline

Packaging & Shipping

Company Profile

Hebei Ritai Original Pipe Co., Ltd. is a core subsidiary of Ritai Group, established in 2001. It is one of the earliest plastic pipe production enterprises in China to achieve professional and large-scale production. Ritai Group specializes in the research, development, and production of plastic pipes. We can provide water and heating systems for residential and commercial buildings, as well as municipal projects. The company is located in the beautiful coastal city of Qinhuangdao. We have nearly 100 modern production lines. All of our products are made of imported high-quality raw materials. The main products include pipes and fittings for underfloor heating systems, water supply and drainage systems, municipal pipelines, etc. Ritai Group has an advanced and comprehensive quality control system. We have passed ISO 9001 (International Quality Management System), ISO 14001 (Environmental Management System), and OHSAS18001 (Health Management System) certifications. All products must pass three levels of inspection: raw material inspection, online production inspection, and finished product inspection. The product has passed the national laboratory testing. To promote the development of industry standards, we actively initiate and participate in the preparation of national and local technical standards and construction specifications; Simultaneously. The company has always stood at the top of the plastic pipeline industry through continuous research and improvement of production processes. The company has a national first-class construction qualification and a professional and high-quality construction team. With advanced pipeline technology, scientific enterprise management, and high-quality services, our business network has developed rapidly, and our products have been sold nationwide and overseas. All sectors of society recognize our role. We have established long-term strategic partnerships with large enterprises such as China Railway Construction, China Construction, Vanke, and COSCO. The company's cumulative sales of pipes have exceeded 400 million meters. The product has been applied to over 8000 projects. We have established long-term strategic partnerships with large enterprises such as China Railway Construction, China Construction, Vanke, and COSCO. The company's cumulative sales of pipes have exceeded 400 million meters. The product has been applied to over 8000 projects. We have established long-term strategic partnerships with large enterprises such as China Railway Construction, China Construction, Vanke, and COSCO. The company's cumulative sales of pipes have exceeded 400 million meters. The product has been applied to over 8000 projects.
Frequently asked questions
Q1. Are you a trading company or a manufacturer?
A: We are a professional manufacturer and welcome your visit at any time.
Q2. What is your delivery time?
A: If the goods are in stock, it usually takes 5-10 days, depending on your quantity and can be negotiated.
Q3: Do you provide samples?
A: Yes, of course, we can provide a small amount of samples for free.
Q4: What are your payment terms?
A: Western Union remittance, advance T/T 30%, balance before shipment.
Q5: What do you mainly do for pipe fittings?
A: For accessories, couplings (sockets), elbows, tees, reducers, unions, valves, caps, some electric fusion accessories, and compression accessories.
Q6: Can I have my own logo on the product?
A: Yes, of course, you just need to send us your drawings and we will make a logo for you. We will confirm with you in advance before production.
Q7: Can I request changes to the packaging and transportation method?
A: Yes, packaging and transportation can be carried out according to your requirements.
