Portable Waterjet Cutter Water Jet Cutting Machine for Cutting Oil Tank, Bomb, Gas Pipe

Product Description

	1. Rated pressure is 420MPa
	2. Working Pressure is 380MPa
	3. Motor power is 15kw
	4. Pump flow is 3.8L/min
	5. Max. thickness is 200mm
	6. Cutting speed10mm Plate: 300mm/min
	7. Machine noise is 60~55db
	8. Dimensions: 1240mm*740mm*900mm
	9. whole machine weight is 1000kg
	10. voltage :380V, 50HZ, 3 Phrase
	11. Water tank capacity: 190L
	12. Abrasive tank volume is 200L
	13. Tank storage amount of sand: 170 kg
	14. Continuous working time: 24 hours per day
	15. Medium: Pure water,Abrasive sand
	16. Abrasive sand size is 100#, 80#
	17. Abrasive sand flow speed: 25kg/H
	18. Nozzle diameter is 0.33mm
	19.water input pressure should be more than 0.4mpa

B Magnet cutting head for gas pipe cutting		1.size: 350mm X 310mm X 180mm 2.weight:20kg 3.cutting pipe diameter: more than 110mm 4.power: 220V/50HZ 5.cutting accuracy: 1mm 6.Magnetic adsorption:more than 50kg
C Magnet cutting head for gas pipe cutting 2		This is need to be design special.

Note: The quotation is subject to seller's final confirmation.
Portable water jet cutting machine with electricity, can be used for cleaning, rust removing and cutting. Pipe cutting, plate cutting,anchor cutter,hole cutting,light rail cutter, applied in
Coal mine, Tunnel, high speed rescue, fire extinguishing, small size, easy to move.
1.High pressure pump characteristics
1.The tamping machine adopts a full explosion-proof design, and all electrical parts are explosion-proof to Exd II BT4.
2. Integrated lightweight structure, user-friendly design and operation is convenient.
3.The function is highly integrated, and field operations do not require additional auxiliary equipment to achieve "true portability".
4.Equipped with high-performance plunger pump imported from Italy, the performance is efficient and stable.
5. Advanced pre-mixing design with Wanlin pressure compensation technology, stable cutting ability and high energy conversion rate.
6.Remote automatic remote control design, the host and cutter can be controlled by one person holding the remote control.
7.The large-size load-bearing wheel is equipped with a small-sized universal wheel, which can be easily moved on bumpy roads.
8.The patented design sand mixing valve can instantly open and close the sand valve, and the sand is evenly smashed.
9. Patented integrated high-pressure sand mixing tank, high safety, high capacity and easy operation.
10.All electrical components are highly stable with Schneider France.
11.Equipped with safety valve, it has overpressure automatic pressure relief function.
12.The water filtration function is used to filter impurities in the water to avoid damage to the host.
13.The water tank has a reverse cleaning function.
14.The host has only a few wearing parts, stable operation and low cost.

Magnetic pipe cutting car performance characteristics:
1.Up to Exd II BT4 explosion-proof level.
2. Lightweight body design.
3. Remote control operation.
4.Ingenious structure design can adapt to the large diameter range of 110mm or more.
5.Equipped with 3000 Gauss large suction magnetic wheel to adapt to a variety of complex conditions.
6.Equipped with 80W, 0.4Nm super-explosion-proof motor to ensure smooth and uniform operation of the car uNder various loads.
7. Equipped with adjustable flexible track to eliminate the unevenness of the cutting surface caused by falling.
8.Equipped with guide wheels to ensure straightness of cutting.
9. sealed water design
10.Electrical, pneumatic and hydraulic power options
