Jez Shoes Mould Laser Cleaning Machine Clean Aluminiium Mould Plastic Residual

Jez Shoes Mould Laser Cleaning Machine Clean Aluminiium Mould Plastic Residual

US$1,944.00-11,944.00 1 Piece (MOQ)

Basic Info.

Model NO.
ZJ-HM120-LC
Control Type
Handheld
Warranty
1 Year
Max Power Consumption
800W
Length of Fiber Cable
5 Meters
Lase Beam Width
100 X 100mm (Option)
Laser Patterns
4 Types
Max Scanning Speed
45, 000mm/S
Operation Language
Multiple
Cooling Way
Air Cooling
Power Supply
1 Phase / 100-240V / 50-60Hz
Warning Light
3 Colors
Emergency Button on Cleaning Head
Yes
Cleaning Head
2D
Easier Clean Mode
Yes
Super Clean Mode
Yes
Alarm Feedback
Yes
Safety Door Function
Yes
Transport Package
Plywood
Specification
900 x 550 x 847 mm
Trademark
SHENHAII
Origin
China
HS Code
8479819000
Production Capacity
1000

Product Description

JEZ 120W Trolley laser cleaning machine very suitable for plastic and rubber residuals removal from shoes mould ,aluminium mould ,the laser cleaner designed and manufactured according to Europe mechanical design requirements .
Specifications (For Reference):
Laser Power 120W
Power Supply 1PH / 100-240V±10% / 50-60HZ / 10A
Cooling Way Air cooling
Power consumption 800W
Length of fiber cable 5 meters
Laser Beam Width 150-500mm(Option)
Laser Beam types 4 different types
Cleaning Head 2D handheld Clean Head
Weight Of Cleaning Head 0.7 KG
Cleaning Head Emergency button Yes
Max Scanning speed 45,000mm/s
Air Blow function to protect Focus lens Yes
Air Blow function to improve working efficiency Yes
Scanning Mode F-Theta
F-Theta Option F254 / F300
Size Of Machine(mm) 900 x 550 x 847
Net Weight Of Machine 124 KG

Product feature :
1: Ultra-high frequency air-cooled pulsed fiber laser for laser cleaning
2. Simple operation and efficient multiple laser cleaning patterns
3. Trolley-style fully enclosed design and light weight handheld cleaning head
4. 3-colors work light self-test function
5. Hand-held cleaning head emergency stop button to cut off laser output in time if any emegency situation
6. Each core component of the machine (laser, water tank, control card, etc.) has a separate circuit protection
7. Alarm feedback of core components (water tank, laser, cleaning head, etc.) to the screen
8. Most of the circuit components are imported brands, which are more durable and stable
9. Adaptive global voltage single phase 100-240V / 50-60Hz
10. Optical accessories are fully wrapped for safe transportation and better buffering effect.
11. Air-cooled laser, no warm-up time required
12. No need for chemicals and other media, green and environmentally friendly cleaning method
Applications:
1. Maintenance of stone artworks, cultural relics, sculptures, etc., non-damage and non-contact cleaning;
2. Remove oil stains from utensils in the food industry without organic solvents
3. Painting of wooden doors and windows, houses, etc., as well as soot cleaning after fires, dry cleaning to prevent mold
4. Urban graffiti cleaning requires no consumables or other auxiliary equipment.
5. Rust removal, paint removal and surface oxide cleaning
6. Injection mould ,shoes mould......daily maintenance
