US$70,423.00-84,507.00
|
1 Piece
(MOQ)
|
Basic Info.
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Movement Method
Linear Control
Control Method
Semi-Closed Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
Economical CNC Machine Tools
Certification
GS, CE, RoHS, ISO 9001
Max Size Workpiece
Ø800×650
Spindle Hole Taper
Bt40/Φ150
Spindle Speed Range
50-8000
Spindle Output Torque Max
116
Transport Package
Plywood Case, Steel Base
Specification
SUJI CKS Series
Production Capacity
1000set/Year
Product Description
Company Profile
Suji Intelligent Equipment Jiangsu Co., Ltd
Suji Intelligent Equipment Jiangsu Co., Ltd was established in 2018 and is located in Jiangsu Shuyang National Economic Development Zone. We specialize in CNC machine tools, including vertical machining centers, with a focus on development, production, research, sales, and service. Our professional technical team has years of experience in CNC machine tool manufacturing, ensuring high-quality and cost-effective machine tools for various industries.
Key Products:
Vertical machining center series
Horizontal machining center series
Gantry machining center series
Flat rail CNC lathe
Inclined rail CNC lathe
Our products are known for their high speed, rigidity, performance, and efficiency, making them the preferred choice for industries such as communication, consumer electronics, medical, LED, automotive, aerospace, and more. We have a strong research and development team, years of manufacturing experience, and are ISO9001 certified, ensuring top-notch quality.
At Suji Intelligent Equipment Jiangsu Co., Ltd, we prioritize quality and service. Our business philosophy revolves around creating value for customers, opportunities for employees, and benefits for society. We are committed to providing professional and sincere service, along with high-quality pre-sale, sale, and after-sales support to meet all customer needs. Join us in creating a better tomorrow!
Product Description
Detailed Photos
Quality Control
Product Parameters
Item/Model | Unit | H500 | H630 | H800 |
WorkBench |
Workbench (L× W) | mm | 600*500 | 630*630 | 800*800 |
Max load | kg | 800 | 1200 | 1500 |
Workbench indexing | Degree | 1 | 1 | 1 |
Number of workbenches | piece | 1 | 1 | 1 |
Max Size workpiece | mm | Ø800×650 | Ø1000×900 | Ø1100x850 |
Travel |
X-axis | mm | 800 | 1050 | 1100 |
Y-axis | mm | 600 | 800 | 850 |
Z-axis | mm | 785 | 900 | 900 |
Spindle center to table face | mm | 50-650 | 80-880 | 100-950 |
Spindle nose to table center | mm | 120-908 | 120-1020 | 180-1080 |
Spindle |
Spindle hole taper | | BT40/Φ150 | BT50/Φ190 | BT50/Φ190 |
Spindle speed range | r/min | 50-8000 | 50-1000 (1:3.5 deceleration), 1000-5000 (1:1.28 deceleration) | 0-6000 |
Spindle output torque Max | Nm | 116 | 408 | 236 |
Speed |
X/Y/Z axis fast movement | m/min | 24 | 24 | 24 |
4-axis rapid movement | r/min | 10 | 10 | 10 |
feed rate | mm/min | 10000 | 10000 | 10000 |
Outline |
Dimensions | mm | 3000*4200*3500 | 3000*4200*3500 | 4500*3500*3500 |
Weight | kg | 8000 | 9500 | 11000 |
Protective cover | | Fully enclosed | Fully enclosed | Fully enclosed |
Accuracy |
X/Y/Z positioning accuracy | mm | ±0.005/500 | ±0.005/500 | ±0.005/300 |
X/Y/Z repeated positioning accuracy | mm | ±0.003/500 | ±0.003/500 | ±0.003/300 |
B-axis positioning accuracy | sec | ±6 | ±6 | 12 |
B-axis repeated positioning accuracy | sec | ±2 | ±2 | 6 |
Other |
Guide rail type X/Y/Z | | X/Y/Z heavy-duty 45 roller track | X/Y heavy-duty 45 roller line rail/Z heavy-duty 55 roller guide rail | X/Y/Z heavy-duty 55 roller track |
Chip removal method | | Double screw and chain chip removal | Double screw and chain chip removal | Double screw and chain chip removal |
Cleaning method | | Manual air gun | Manual air gun | Manual air gun |
Spindle protection/cooling method | | Air curtain/annular water spray | Air curtain/annular water spray | Air curtain/annular water spray |
Accuracy level of linear roller guide rail | | P4 | P4 | P4 |
Accuracy level of ball screw | | C3 | C3 | C3 |
Brands of Main Parts
Part Name | Origin | Manufacturer | Model |
CNC system | FANUC, Japan | FANUC | 0i-MF PLUS(Type 3) |
Servo feed motor | FANUC, Japan | FANUC | |
Servo spindle motor | FANUC, Japan | FANUC | |
Servo integrated driver | FANUC, Japan | FANUC | |
Spindle group | Taiwan | Royal/Kenturn | BT40-φ150 |
Roller screw | Taiwan | HIWIN/PMI | FDC4012 |
Linear guide rail | Taiwan | HIWIN/PMI | 45#/45#/45# |
Spindle bearing | China mainland | NSK | |
Unclamping Cylinder | Taiwan | Haocheng | 4.5T |
Disk type tool magazine | Taiwan | Ammach/Tokuda/Okada | BT40-24T |
Locking nut | Taiwan | Svit | M30×1.5P/ M35×1.5P |
coupling | China mainland | Sanmu | |
heat exchanger | China mainland | Miki Pully | EA-02W/220V |
Screw bearing | China mainland | NSK | 30TAB062 |
Oiling machine | China mainland | Ishan | |
Main electrical components | France | Scchneider | |
Pneumatic components | Taiwan | TWSNS | |
Chain chip conveyor | China mainland | SUJI | |
