Automatic Intermittent Centrifuge Large Capacity Centrifugal Tube Machine

Product Description

Mechanical Centrifuge
A mechanical centrifuge can be used to obtain virgin coconut oil, which is considered to be one of the purest forms. During this process, coconut meat is emptied into a machine which chops the meat into tiny pieces. These little pieces are placed into a light screw press and the milk is extracted from the meat; then, the remaining coconut is placed in a high speed mechanical centrifuge which rapidly spins the coconut.
Through the spinning process, the oil is separated from the meat and collected. Mechanical centrifuge
coconut oil retains a strong coconut taste and smell and requires no refining processes.

Centrifugal process
As the name suggest the key aspect of the whole method is centrifuge.
A centrifuge is a an equipment driven by electricity which rotates around a fixed axis.
You must have seen a washing machine dryer, it works on the same principle - drum
acts as centrifuge and water is literally forced out due to the fast spinning.
How does this work in case of coconut oil?
In case of coconut oil extraction using centrifugal method the first step is to produce coconut milk using fresh mature coconut meat. Coconut milk actually is a natural oil in water emulsion.An emulsion consists of two immiscible liquids, where one is dispersed as very fine droplets into another. When kept for sometime this unstable emulsion starts separating but takes too much time, this is where centrifugal process helps.With the use of centrifugal process the separation speed of oil and water is greatly enhanced without using any chemical process of heat. As centrifuge moves, coconut oils starts moving
towards the its centre and then can be collected. This separates coconut oil and water.
The feature of GF centrifuge:
1.Rapid separations
2.Consistent performance
3.Range of models: facilitate scale-up
4.Simple to set up, use and clean-for minimal down-time between separations
5.No replacement membranes, or costly disposables
6.small footprint----saves space
7.Enclosed models available-for ambient gas control
8.CIP/SIP models available
9.Cooling system available by cooling coil with refrigerants
Typical Application
It is mainly used for liquid-liquid-solid or liquid-liquid separation. For example:
1) Separation of blood(plasma and hemoglobin separation)
2) Vegetable Oil separation( degum, de-soap, water washing etc)
3) Animal oil separation ( fish oil, shrimp oil etc)
4) Industrial oil separation (HFO, WVO, bio-diesel, lubricating oil, distillate oil, transformer oil,
hydraulic oil etc)
5) Oil extraction(Rose essence oil, orange oil, lemongrass essential oil sea buckthron oil etc)
6) Waste water handling
7) Milk skimming, coconut oil and water separation
The process of extract coconut oil by centrifuge:
1.If the solid content of coconut milk is very less.The coconut milk can directly into the tubular centrifuge (3 phase) or disc centrifuge(3phase).
2.If the solid content of coconut milk not very more.The coconut milk can first into disc centrifuge(2phase),second into the tubular centrifuge(3phase).
3.If the solid content of coconut milk is very more.The coconut milk can first into filter
centrifuge(2phase),second into disc centrifuge(2phase or 3phase),thirdly into the tubular centrifuge(3phase).
Technial Parameter:

ITEM		GQ/GF75	GQ/GF105	GQ/GF125		GQ/GF150
Drum	ID(mm)	75	105	125		147
	Height (mm)	450	730	730		730
	Sedimentation volume(L)	2.67	6	8		10
	Max speed(r/min)	21000	17500	16500		15800
	Max separation factor	22500	18500	17300		16800
	Inlet nozzle diameter (mm)	3/4/6	4/6/8	6/8/10		8/10/12
	Material inlet pressure (Mpa)	≥0.05
	Capacity (water capacity)L/H	670	1600	2200		3200
	Actually Capacity L/H(according to the solid content)	50-80	100-200	200-300		300-700
Motor model		3 phase two pole motor
Motor power (kw)		1.5	2.2		3		3
Machine dimension (mm)		500*700*1300	600*1000*1600		600*1000*1600		600*1000*1600
Machine weight (kg)		300	460		490		510

Spare parts show of the tubular centrifuge:
FAQ
Q1: Where can I get product & price information?
A1: Send us inquiry or email directly, then we will contact you ASAP.
Q2: How can I make sure your machinery is suitable for me?
A2: Please tell all the separation information you know, such as your raw liquid,
two-phase or three-phase separation, solid content in liquid, solid size, the purpose, etc. After analyzing your information, we will to choose a suitable model for you, and send the details and videos to you.
Q3: What should I do if I want to see the separation effect?
A3: If you can come to our factory with the raw liquid, we will provide test service. Or you deliver the raw liquid to us, and we will do a test, and supply you the testing videos.
Q4: How to enjoy the OEM services?
A4: As the manufacturer of the machine, we will try our best to satisfy you if you have any specific requirement, such as the cover device, drum size, motor voltage, etc.
