SATA3 SSD 240GB 120GB 960GB 2tb 480GB SSD Solid State Drive

Product Description

ULIKE DESIGN CO. LIMITED founded in China.
We are a professional electronics supplier specializing in the design and sales of consumer electronic products including:USB Flash Drive,SD Card,TF Card,SSD and RAM products By accumulation of over 10 years industry experience.
Ulike Design has set up long partnership relationship with lots of overseas customers. Ulike Design strives to deliver products and services with honesty and speed. We hope to privde cusotmer with private and idea designed products. Specification
2.5 Inch SATA3 SSD 240GB 120GB 960GB 2TB 480GB External SSD

Application:	Can be used on Laptops, Notebooks, Advertising Machine, ATM machine, etc..
SATA protocol:	Compliant with SATA 6Gbp/s specification(compatible with SATA 1.5/3.0/6.0Gb/s interface)
support system:	Windows 8/Windows 7/Windows Server 2003 (32 bit and 64 bit), Vista (SP1 and above), XP (SP2 and above), MAC OSX and Linux
Data retention:	>10 years
MTBF:	> 1000,000 hours
Trustworthy and Reliable:	Supports TRIM command, Garbage Collection technology, RAID, and ECC (Error Checking & Correction) to provide the optimized performance and enhanced reliability
Storage temperature:	-40 to +85°C
Operating temperature:	0°C to +70°C
Certificate:	CE,FCC,ROHS
Warranty:	3 years

Key Specifications/ Special Features:Specifications:
High speed SATA3 SSD, with R/W speed: 500/400MB/s
Can be used on laptop, desktop and enterprise device
Compliant with SATA 6Gbps specification
Capacity: 60GB-4TB
Low power consumption
Noise free, shock resistant
ECC correction code
MTBF: more than 1,000,000 hours
Physical dimension: 100.2*69.8*9.5mm
Certifications: CE, RoHS Directive-compliant, FCC
Maximum read 500MB/s, maximum write 500MB/s
Random write (4k): up to 64,000 IOPS
Order terms:
Price terms: EXW Shenzhen
Packing terms: retail or bulk packing
Payment terms: T/T and Western Union
Delivery time: 2- 4 working days
Warranty: 3 year
OEM and ODM are also available Functions and Features of SSDFunctionsData Storage: SSDs are used to store operating systems, applications, and data files.Fast Boot: SSDs can speed up system boot times and application load times.Data Read and Write: SSDs provide high-speed data read and write capabilities, enhancing overall system performance.High Reliability: SSDs have no mechanical parts, making them more reliable in mobile or vibrating environments.Lower Power Consumption: Compared to traditional hard drives (HDDs), SSDs consume less power, helping to extend battery life.FeaturesHigh-Speed Performance: SSDs offer faster read and write speeds than HDDs, generally reaching 500MB/s or higher.Noise-Free: SSDs operate with virtually no noise due to the lack of mechanical parts.Lightweight and Portable: SSDs are small and light, making them ideal for laptops and ultra-thin devices.Low Latency: SSDs have low latency, making them more efficient for handling random read/write operations.Long Lifespan: Modern SSDs use advanced error correction and wear leveling technologies to extend their lifespan.Shock and Vibration Resistant: SSDs are highly resistant to shocks, making them suitable for environments with frequent movement.Various Capacities: SSDs come in a range of capacities to meet different user needs, from a few hundred GB to several TB.Temperature Resilience: SSDs perform well in extreme temperatures, making them less susceptible to environmental conditions.These features make SSDs widely used in modern computing devices, including desktops, laptops, servers, and data centers.
Functions and Features of 2.5-inch SATA SSDFunctionsData Storage: Used to store operating systems, applications, and user data.System Acceleration: Significantly improves system boot speed and application load times.Data Transfer: Provides efficient data read and write capabilities, suitable for large file transfers and data backups.Performance Enhancement: Enhances overall system performance in multitasking and high-load applications.Compatibility: Compatible with most modern computing devices through the SATA interface.FeaturesHigh-Speed Performance: 2.5-inch SATA SSDs generally offer high read and write speeds, typically reaching up to 500MB/s read speed and 400MB/s write speed.Standard Size: The 2.5-inch form factor is a standard size suitable for most laptops and desktops.Noise-Free: Operates with no noise due to the absence of mechanical parts.Low Power Consumption: Consumes less power compared to HDDs, helping to extend laptop battery life.High Reliability: With no mechanical parts, SSDs are more shock and drop-resistant, making them highly reliable for mobile devices.Durability: Uses advanced wear leveling and error correction technologies to extend lifespan.Lightweight: Lightweight and easy to carry and install.Good Compatibility: Compatible with most computing devices via the standard SATA interface, making it easy to upgrade and replace.Affordable Pricing: More affordable compared to other types of SSDs like NVMe, making it suitable for general users.Wide Range of Capacities: Available in various capacities from 120GB to 4TB, meeting different storage needs. Product Description
Detailed Photos
Performance test
About SSD performance test
1.Our speed test is base on SATA 3.0 interface
Difference between SATA I, SATA II and SATA III
SATA I (revision 1.x) interface, formally known as SATA 1.5Gb/s , is the first generation SATA interface running at 1.5 Gb/s. Max speed 150MB/s.
SATA II (revision 2.x) interface, formally known as SATA 3Gb/s, is a second generation SATA interface running at 3.0 Gb/s. Max speed 300MB/s.
SATA III (revision 3.x) interface, formally known as SATA 6Gb/s, is a third generation SATA interface running at 6.0Gb/s. Max speed 600MB/s. This interface is backwards compatible with SATA 3 Gb/s interface.
If sata3.0 SSD tested speed on sata2.0 interface and sata cable, then the result will be inaccurate.
2. Due to different platform or software, the result will be a little difference(we usually use CrystaDisk and AS SSD Benchmark test Our SSD)
Why the capacity display from computer is smaller than original capacity?
1. In factory, we use 1000KB=1MB for calculate, also we use a little space as the Bad Bolck Management software for SSD's stable using, the real capacity will be: Capacity x 0.93, Pls notice that all of the SSD must have the Bad Block Management sofeware for its running well.
Actual capacity calculation: Total storage x 0.93
Factory default setting :1GB=1000MB=1000000KB=1000000000B Computer
system setting:1GB=1024MB=1048576KB=1073741824B
For Example: 360GB SSD
Factory capacity: 360x1000x1000x1000=360000000000B
In computer show actual capacity: 360000000000B/1024/1024/1024=335G Fast calculation: 360Gx0.93=335G
Certifications
Our certifications
Packaging & Shipping
FAQ
FAQ
1 Can we custom our logo on the SSD?
We support customized logo and customized package(MOQ 1000pcs)
2 What kinds of logo we can put on the SSD?
Generally they are silk printing ,laser logo,full printing, pad printing or epoxy logo.
3 How to make the payment?
We accept T/T,Paypal(5% commission),Western Union,And if you pay by RMB,Alipay,wechat,bank transfer,cash
4 Do you have samples?
Yes! For regular items, we will keep stock. You can ask for dummy samples or real samples. The samples can be shipped by your express account, or you can pay us the freight, and we will ship via our account.
5 How long we can get the goods?
It depend on the QTY.
<1000 4-6 days
1000-5000pcs 7-15 days
5001-10000pcs 15-25days
6 What is the minimum quantity?
Minimum order quantities (MOQ) are listed on each individual product page. Minimums may be higher for custom products colors. Orders for less than the stated minimum may be possible with a less than minimum (LTM) charge. No imprinted orders will be accepted for less than 50% of the listed MOQ. Blank product may be available at a lower MOQ, please consult your WORTHSPARK Representative as this is depend on stock.
7 Warranties & Returns
Warranty - All of our products are guaranteed against defects for 1 year.
8 How about the shipment
We ship the goods by sea or Express as DHL,TNT,FedEx.
