Mud Logging Sensor Named Drawwork Sensor/Winch Sensor

Mud Logging Sensor Named Drawwork Sensor/Winch Sensor

US$852.00 1 Piece (MOQ)

Basic Info.

Model NO.
Luckway
Out-Wire
4-Wire
Output Signal Type
Analog Type
Feature
Low Temperature Resistant
Production Process
Normal Wirewound
Material
Stainless Steel
IP Rating
IP65
Certification
RoHS
Customized
Customized
Safe Overload
150%F.S
Construction
Alloy Steel
Zero Balance
1%F.S
Ultimate Overload
200%F.S
Transport Package
Carton
Specification
80*12.7*12.7
Origin
China
Production Capacity
10000PCS/Month

Packaging & Delivery

Package Size
30.00cm * 20.00cm * 20.00cm
Package Gross Weight
5.000kg

Product Description

CNPS-DW-A11 Depth encoder is a new type of low temperature resistance winch sensor. It has the advantages of small size, compact structure, good sealing performance, high sensitivity, stable output signal, good anti-interference, accurate measurement and so on. The product can be compatible with imported hoist sensors of the same type, and is a new type of sensor in oil drilling and geological logging.
1.Working Principle
The winch sensor is installed on the winch shaft to monitor the angular displacement caused by the rotation of the winch shaft during the whole drilling process. Through calculation, the change of hook height during drilling can be obtained, and the current drilling depth can be obtained.
CNPS-DW-A11 winch sensor is equipped with two photoelectric switches and a piece of shield with teeth. When the shield rotates with the winch shaft, the infrared light in the gap between the two photoelectric switches in the sensor is blocked or turned on, and two sets of corresponding electrical pulse signals are sent to the instrument after recognition and processing. The corresponding direction and variation of angular displacement can be obtained.
2.Technical Indicators
Working voltage: 5V DC
Output level: high level 5V; low level 0V.
Working temperature: - 40 C ~ 80 C
Power consumption: 250MW
Response time: 150 S

capacity Kg 1~20Kg
Rated Output mv/v 1.0±0.15
Non-linearity %F.S 0.05%F.S
Hysteresis %F.S 0.05
Repeatability %F.S 0.05
Creep %F.S/3min 0.05
Temp.effect on zero %F.S/10ºC 0.05%F.S
Temp.effect on span %F.S/10ºC 0.05%F.S
Zero balance mv/v ±0.05
Input impedance Ω 1000±6
Output impedance Ω 1000±5
Insulation resistance ≥2000(100VDC)
Recommended excitation voltage VDC 3~10
Allowed excitation voltage VDC 3~12
Compensated temp.Range ºC -10ºC~+40ºC
Operating temp.Range ºC 0ºC~+40ºC
Safe overload %F.S 120
Ultimate Overload %F.S 150
Connection Excitation: Red:+ Black:-
Signal: Green:+ White:-
FAQ
FAQ Q: Are you trading company or manufacturer ? A: We are manufacturer in China. Q: What is your MOQ?
A: As customer's request ( For example: FLANGE DN20, MOQ 500KGS).
Q: Can you provide a sample?
A:Sure, Our sample is provided free of charge, but not including courier fees.
Q: What is your terms of payment ?
A: Payment<=5000USD, 100% in advance. Payment>=5000USD 50%T/T in advance 50%balance before shippment.
