Vertical Universal Drilling and Milling Machine with High Precision 16mm (ZX7016)

Vertical Universal Drilling and Milling Machine with High Precision 16mm (ZX7016)

US$893.00 1 Piece (MOQ)

Basic Info.

Model NO.
ZX7016
Structure
Desktop
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
High Precision
Certification
ISO 9001
Condition
New
Main Function
Drilling,Milling
Applicable Materials
The Casting Iron etc. Metal
Transmission Way
Belt Driving
The Type
Desktop,Deluxe Stand Is Optional
Functional
High Preision and Low Noise
Material
Mental Steels
Feeding Perfomance
Hand Feeding and Jiggle Feeding
Color
Green
Shape
Strong and Beautiful
Max. Drilling
32mm
Transport Package
Wooden
Specification
97× 56× 99cm
Trademark
WESTLAKE
Origin
Hangzhou Zhejiang
HS Code
8459699000
Production Capacity
2000PCS/Year

Product Description

COMPANY PROFILE
Hangzhou West Lake Drilling Machine Co ., Ltd . is the largest manufacturer of drilling presses , milling / drilling machines and tapping machines in China , which was established fifty years ago and has been always on the top of quality , production and varieties in the field of bench drills in China .
With brand " Westlake ", our products have been served for international market since 1956. You may find them widely used in different fields around the country and more than 60 countries / areas worldwide at present . Westlake is one of the most famous trademark among China machine and electric products for exportation , enjoying a high reputation by all customers both domestically and overseas .
Equipped with a R & D center , Metrology and test center , we have advanced product and test equipment such as CNC , Composite Machine Tool , Coordinate Measuring Machine and laser interferometer etc . Our company is experienced and strong in product design and manufacture , in constant pursue of advanced technology and continuous development of CNC . Currently we are supplying three series of Westlake drilling machines , Westlake Precision Machine and Westlake compact - sized CNC with more than one hundred types of products .
we obtained ISO9002QA and ISO9001:2000 certification as early as 1996 and 2002 respectively . Our products have obtained Germany GS and Europe CE certification as well .
Product Description
Main Feature:
1.16mm drilling & milling machine.Deluxe stand is optional.
2.Belt driving,low noise.
3.The belt will skid when the machine is over load.
4.High precision
Technical Data:
Max. drilling capacity 16mm
Width of face milling 50mm
Diameter of vertical milling 12mm
Spindle travel 115mm
Distance spindle axis to column surface 240mm
Max. distance spindle nose to worktable 307mm
Spindle taper MT.2
Spindle speeds range 235-2050rpm
Spindle speeds 5
Dimension of table 430×200mm
Travel of worktable 236×128mm
Overall height 967mm
Headstock travel 300mm
Motor 550w
G.W./N.W. 230/190kgs
Ship measurement 97×56×99cm

The Picture of Machine (The base is separate and quoted separately)
FAQ:
1.Question : Are you a factory or trading company ?
Answer: We are an SGS recognized OEM / ODM manufacturer factory with export license. we have an experienced team made up of "A" player who have a passion for doing something great to create more value for customers world-wide.

2. Question : Why choose cooperate with us ?
Answer :
--Reliable Quality and All components from world leading suppliers ;
--Cost-effective export infrastructure and total supply chain management ;
3. Question : Where is your factory located ? How can I visit there ?
Answer: With an ISO90001 certified factory located in Hangzhou city, Zhejiang Province, China . It takes about 1 hours from Shanghai by high speed train. Warmly welcome clients to visit us .
4. Question : Can you do OEM ?
Answer : Yes, we have the ability to do OEM / ODM to meet clients' requirements.
5. Question : How does your factory do regarding quality control ?
Answer: Reliable Quality is our dignity and we do quality checking carefully such as Incoming Quality Control, In Process Quality Control, Outgoing Quality Control , Environment Control, Product Traceabitity System , Internal Audits & Calibration, Equipment Control & Maintenance, Control of Non-Conforming Materials and etc.
Welcome to visit our company website (http://wl-mach.en.made-in-china.com/)to send enquiry to us so you would get the best factory direct price,it is only for you !
