Hck 150 Ton Haichen Disposable Hookah Injection Plastic Molding Machine Hookah Hose Making Machine

Hck 150 Ton Haichen Disposable Hookah Injection Plastic Molding Machine Hookah Hose Making Machine

US$19,000.00 1 sets (MOQ)

Basic Info.

Model NO.
HCK 150 ton
Type
Tube Head Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE
Used for
Plasic Products
Injection Rate (G/S)
130
Injection Pressure
1745
Ejector Force(kN)
40
Ejector Number
5
Ejector Stroke(mm)
130
Screw Diameter (mm)
40
Injection Weight (G)
229
Oiltank Cubage
260
Machine Type
Hydraulic
Plasticizing Capacity(G/S
17
Theoretical Shot Volume(Cm)
251
Heating Power
10
Power (Kw)
7.5
Distance Between Tie Bars
460*410
Transport Package
Wooden
Specification
HCK150
Trademark
Haichen
Origin
China
HS Code
8477101090

Product Description

HCK 150 ton Haichen disposable hookah injection plastic molding machine hookah hose making machine

Hookah tube injection molding machine is a kind of injection molding machine, by heating and melting thermoplastics (such as PVC, ABS) into the mold, cooling and forming into a tubular structure of hookah tube.
It is characterized by the efficient production of tubes with precise dimensions and smooth surfaces, and supports the forming of complex structures such as corrugations, slubs, etc.
Product description
We are prefessional production base specialized in designing and manufacturing plastic injection machines and enjoy high reputation in the Plastic machinery industry.
Structural characteristics and material selection of hookah pipes Structural features:
Multi-component integration:
Including cigarette holders, cigarette pipes, water bottle connections, etc., and some components need internal thread or buckle structure.
Tightness requirements:
The interface between the smoke pipe and the water bottle should be strictly leak-proof, and the parting surface of the mold should be designed to avoid burrs.
Decorative requirements:
The surface often needs to be engraved or transparent, and the material needs to be high-gloss or easy to color.
Material selection:
Heat-resistant plastics: such as polypropylene (PP), polycarbonate (PC), resistant to tobacco combustion waste heat.
Transparent materials, such as PMMA, are used for glass imitation water bottle parts.
Food grade approval: The mouthpiece is in contact with the mouth, and it must comply with FDA or EU 10/2011 standards.
Picture Raw material Weight Cavity Cycle time Injection molding machine Chiller Dryer Autoloader Crusher Mixer
PP 10g 2 16s 140T 08ACI 100kg 600GN XFS-230 50kg

The moulds can be costomized.
Technical Parameters
1. Designed by 3D software,structural strength are verified.
2. CNC machine tools for processing, products are of high precision.
3. T slot, threaded holes for mold installation.
4.Hydraulic system with a self sealing oil suction filter and adopted the bypass filter device.
