High Quality Pqwt Underground Water Leak Detection Equipment 500m Deep Ground Water Scanning Detector

Product Description

Product Description
Introduction of PQWT-TC1200 Automatic Groundwater Mapper
Main features
1. Fast measuring speed, high efficiency, easy to carry, simple operation, high accuracy and strong anti-interference ability.
2. Automatically draw curve diagrams and geological profiles, abandoning the steps of computerized mapping required by previous instruments, making the operation simpler and more convenient.
3. Automatic measurement, automatic data storage, automatic curve drawing. No need to record data. Data will not be lost after power off
4. 999 measurement curves can be stored. Can directly display or export data files, curve diagrams, profiles.
5. Adopt rechargeable battery power supply, up to more than 12 hours standby time.
Instrument working principle
Geophysical exploration is the detection of stratum rocks, geological formations and other geological through the study and observation of various geophysical field conditions change.
Commonly used geophysical exploration methods are gravity exploration, DC exploration, seismic exploration, etc., alternating current (AC) power exploration, magnetic exploration, acoustic wave exploration, seismic exploration exploration, radiological exploration, the main geological exploration instrument is currently on the market for power exploration. Most of the instruments have complex features operational, heavy weight, post-data processing is too complex, the user must be many years of experienced technicians, before using electricity must be professionally trained
Exploration Instruments.
TC series of natural electric field geophysical exploration groundwater detector I developed the latest products, the use of a number of patented technologies.
Instrument weight is light, easy to carry, the length of the measurement line is only 5-10 meters, a person can also complete the operation, saving manpower and time, the full touch LCD screen, easy to operate, the external insertion of large-capacity memory card, the instrument has a real-time mapping function to find the high-resistance (fracture zones), low-resistance (such as the detection of water and ore bodies) through the real-time mapping, can be directly displayed on the geological site structural anomalies.
Main Functions
Natural electric field frequency optional geological exploration, controlled source audio geomagnetic method (CSAMT) and audio geomagnetic method (AMT).
zmwm22
Product Parameters

Model

Depth

range

Accuracy

Channel

Frequency

LCD Display

Optional language

A/D conversion

Impedance

power

consumption

operation temperature

offside

PQWT-TC150

150 meters

0-2000mV, instrument automatic conversion

0.001mv

4

Single frequency, triple frequency, 33 frequency

Industrial 7-inch high-definition touch screen

Chinese, English, French, Arabic

12 bit 1MSP

>=10MΩ

DC12V4000mAh built-in battery

About 4W

-10°C~50°C

<=85%

PQWT-TC300

300 meters

6

Single frequency, triple frequency, 40 frequency

PQWT-TC500

500 meters

8

Single frequency, triple frequency, 56 frequency

PQWT-TC700

150 meters/300 meters/500 meters/600 meters (optional)

8

Single frequency, triple frequency, multi frequency

8 bit 1MSP

26650 * 2 4000mAh lithium-ion rechargeable batteries

-20°C~50°C

PQWT-TC900

150 meters/300 meters/600 meters/1200 meters (optional)

8

Single frequency, triple frequency, multi frequency

16 bit 1MSP

PQWT-TC1200

600 meters/900 meters/1500 meters/custom frequency (optional)

8

Single frequency, triple frequency, multi frequency

16 bit 1MSP

Special power box with controllable reference source

PQWT-S150

100 meters/150 meters (optional)

0-1000mV, instrument automatic conversion

0.001mv

3

Single frequency, triple frequency, 36 frequency

320*420 LCD screen

--

8 bit 1MSP

>=10MΩ

Two 3.7V 4000mAh rechargeable lithium batteries

About 4W

-10°C~50°C

<=85%

PQWT-S400

150 meters/300 meters/500 meters (optional)

6

Single frequency, triple frequency, 36 frequency, 40 frequency

16 bit 1MSP

PQWT-S500

100 meters/150 meters/300 meters (optional)

7

800X480 LCD screen

12 bit 1MSP

PQWT-M100

100 meters

0-1000mV, instrument automatic conversion

0.001mv

4

30 frequency

LCD screen

--

8 bit 1MSP

>=10MΩ

18650 * 2-cell 3000mAh rechargeable lithium battery

About 1W

-20°C~50°C

<=85%
