2.5 Ton 3.5 Ton Digger Micro Size Free Shipping Digger CE Mini Excavator for Factory Price Excavators Machine Cheap 3 Ton Mini Amphibious 5ton Excavator
| US$1,999.00-11,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
VTW-26
Type
Crawler Excavator
Usage
Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
Bucket
Shovel
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.02 ~ 0.26 Cbm
Size
Small-Scale
Certification
CE, ISO9001: 2000
Condition
New
OEM Supported
Yes
Rated Speed
0 ~ 5 Km/H
Moving Type
Self-Propelled
Gradeability
35 Degree
Engine
Yanmar /Changchai /Koop
Engine Type
Water Cooling/Air Cooled
Rated Power
7.5-34kw
Transmission Type
Hydraulic/Mechanical
Crawler Material
Rubber/Steel
Crawler Type
General/Telescopic
Operating System
Mechanical/Hydraulic Pilot
Closed Cab
Optional
Max. Digging Radius
2400-3860mm
Max. Digging Depth
1200-2545mm
Transport Package
Standard Exported Wooden Case
Specification
0.8 Ton to 3.5 Ton
Trademark
VOTE
Origin
Shandong, China (Mainland)
HS Code
8429521200
Production Capacity
100 / Month
Packaging & Delivery
Package Size
300.00cm * 200.00cm * 200.00cm
Package Gross Weight
1000.000kg
Product Description
3.5 Ton Digger Micro Size Free-shipping Digger Ce Mini Excavator For Sale Pursue High Quality ExcavatorsWe Welcome You To Visit Our Factory To Check Our Production Lines And Know More About Our Capacity Quality.
We Have Iso, Ce And Our Own Quality Control Team.
We Could Personalize Product'S Color And Other Things.
Our Goal Is To Help Customers Save Money And Help Customers Make Money.
Why Not To Have A Try To Send Inquiry Below To Us?
| Model | VTW-18S | VTW-20S | VTW-26S | VTW-35S |
| Total Weight | 1800 kg | 2000 kg | 2600 kg | 3500 kg |
| Rated Power | 11.8 kw/rpm | 10.3 kw/rpm 11.8 kw/rpm | 15 kw/rpm | 15 kw/rpm |
| Engine | Yanma3TNV70 | Yanmar3TNV70 KubotaD902 | Yanmar3TNV76-P | Yanmar3TNV76-P |
| Bucket Capacity | 0.04m³ | 0.04 m³ | 0.066 m³ | 0.066 m³ |
| Maximum digging distance | 3500 mm | 3600 mm | 4200 mm | 4500 mm |
| Max. Digging Depth | 2120 mm | 2310 mm | 2320 mm | 2820 mm |
| Max. Digging Height | 3310 mm | 3540 mm | 3880 mm | 4122 mm |
| Gradeability | 58(30)° | 58(30)° | 58(30)° | 58(30)° |
| Overall Width | 1110 mm | 990/1240 mm | 1300/1500 mm | 1300/1500 mm |
1. Excavators with compact dimensions can easily drive through narrow passages and doors.
2. Retractable undercarriage and dozer blade allow the excavators to be configured for excellent working stability and optimum performance.
3. Powerful engine and perfectly matched hydraulics provide efficient, economical and reliable performance for the toughest of jobs.
4. Bucket hoses are well protected within the boom and the cylinder is mounted above the structure.
5. The operator area is spacious and laid out to provide comfort and ease of operation.
6. Excellent engine provides excellent power with minimal fuel use for more productivity per tank.
