Fire Fighting System Water Foam Spray Nozzle
| US$0.80-2.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
PTW
Alarm Valve Type
Wet Alarm Valve
Automatically Opened and Closed Repeatedly
Can′t Automatically Opened and Closed
Closed Fire Sprinkler System
Wet Fire Sprinkler System
Wet Alarm Valve Structure
Seat Type
Norminal Diameter(mm)
15mm/20mm/25mm
Material
Brass/Stainless Steel
Working Pressure
0.3-0.6MPa
Flow of Mixture Liquid
0.9L/S, 1.2L/S, 1.5L/S, 1.75L/S
Foam Expansion
More Than 5
Installation Height
More Than 2.5m
Transport Package
Standard Export Package
Specification
1/2" 3/4" 1"
Trademark
SINCO or OEM
Origin
Quanzhou, Fujian
HS Code
8424
Production Capacity
150000pieces/Month
Product Description
Fire Fighting System Water Foam Spray NozzleIntroduction
The foam sprinkler is a special fire extinguishing parts mainly used in low-expansion foam spray system which can produce and jet air bubble. Foam proportionate system supply foam solution for these nozzles. When foam solution was conveyed to nozzles by pipelines, the nozzle inhales air at outlet to make foams and put out fire.
Working Principle
When pressurized foam solution flows through the cavity of the nozzle, its pressure will be reduced because of throttling. That will result in vacuum and inhale air. The foam solution then become foams after dispersed by nozzle.
Technical Parameters
| Size | Working pressure | Flow of mixture liquid | Flow parameter | Foam expansion | Installation height | Connecting thread |
| Mpa | L/S | L/S | Times | m | Inch | |
| PTW0.9 | 0.3-0.6 | 0.9 | 27 | ≥6 | ≥2.5 | 1/2" 3/4" 1" |
| PTW1.2 | 1.2 | 36 | ||||
| PTW1.5 | 1.5 | 45 | ||||
| PTW1.75 | 1.75 | 53 |
