Double Stage PP PE Fiber/Fabric/Non-Woven/Woven Raffia/Film Plastic Recycling Pelletizing Granulating Line
| US$30,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
RCSJ RCDJ
Material Processed
Film
Plastic Type
PE
Screw
Single-Screw
Automation
Automation
Computerized
Computerized
Certification
ISO9001:2008, CE
Cutting Way
Die Face Cutting
Granules Size
5mm
Degassing
Vacuum Degassing
Humidity
1%
Transport Package
by Sea
Specification
TSSJ100~200 THSJ65~220 TCSJ85~180 TCDJ85~180
Trademark
RETECH
Origin
China
HS Code
8477201000
Production Capacity
100 Sets Per Year
Packaging & Delivery
Package Size
1500.00cm * 500.00cm * 500.00cm
Package Gross Weight
12000.000kg
Product Description
Double Stage PP PE Fiber Fabric Non-Woven Woven Raffia Film Plastic Recycling Pelletizing Granulating LineProduct Description
Our PE PP plastic film pelletizing machines consist of extruders, pelletizers, cooling tanks (or air-cooled equipment). Plastic film granulation equipment is complete, can be automatic continuous production, direct granulation, and granulation is clean, pollution-free and aging phenomenon, greatly reducing production costs and improving production efficiency. Plastic film granulation equipment has the remarkable characteristics of small size, high efficiency, good performance, low power consumption, high quality of finished products and wide adaptability, and can be adapted to meet various processing requirements.
Features
Detailed Photos
Product Parameters
| Model | Diameter of screw | PE capacity | PP capacity |
| RCDJ-85 | Φ85mm | 150-200kg/h | 100-150kg/h |
| RCSJ-85/100 | Φ85/85mm | 150-200kg/h | 100-150kg/h |
| RCDJ-100 | Φ100mm | 280-350kg/h | 250-300kg/h |
| RCSJ-100/120 | Φ100/100mm | 280-350kg/h | 250-300kg/h |
| RCDJ-130 | Φ130mm | 480-550kg/h | 400-500kg/h |
| RCSJ-130/150 | Φ130/130mm | 480-550kg/h | 400-500kg/h |
| RCDJ-160 | Φ160mm | 650-800kg/h | 600-750kg/h |
| RCSJ-160/180 | Φ160/160mm | 650-800kg/h | 600-750kg/h |
| RCDJ-180 | Φ180mm | 800-1200kg/h | 750-1000kg/h |
| RCSJ-180/200 | Φ180/180mm | 800-1200kg/h | 750-1000kg/h |
Solution
| No. | Name | Picture |
| 1 | Belt conveyor with metal detector Motor power:2.2kw Length:5m Material of belt:PVC Function: To convey plastic into compactor,metal detector will alarm when find metals. | |
| 2 | Compactor Motor power:37kw-132kw Moving speed:600RPM Blades material:NO.6452 Function: To cut/heat/agglomerate film and send it to extruder | |
| 3 | RCSJ model main extruder Power:55kw-250kw Degassing:Vacuum degassing Screw diameter:85mm-180mm Screw material:Bimetal/38CrMoA1A L/D:33:1,28:1 Function: To melting plastic and remove air impurities by degassing system | |
| 4 | RCSJ180/12 main extruder Power:22kw-110kw Screw diameter:100mm-200mm | |
| 5 | Hydrualic screen exchanger Plate type. Function: To filter and stop impurities. | |
| 6 | Die face cutting system Cutting power:2.2kw-3kw Water pump:3kw-4kw Function: To cut plastic into granules Horizontal cutter Vertical cutter |
