Flue Gas Humidity Analyzer for Humidity Measurement of Desulfurization and Denitrification Flue Gas in Cems

Product Description

Flue Gas Humidity Analyzer for humidity measurement of desulfurization and denitrification flue gas in CEMS
Application of Flue Gas Humidity Analyzer:
It could be widely applied in the humidity measurement of desulfurization and denitrification flue gas in CEMS, also in the humidity monitoring in the process of timber, building material, papermaking, chemical industry, pharmacy, fiber, spinning, tobacco, vegetable and food.
Notes:if coming across an circumstance with low temperature, high humidity and high dust, we would offer you with a proper solution for flue gas humidity.
Instrument features of Flue Gas Humidity Analyzer:
• The integrative design is convenient for the installation, and reduces the influence from external interference on the measured value;
• Auto-compensation function for temperature with high accuracy eliminates the influence from the environment temperature;
• The unique heat-tracing design could avoid the solidification of sulfide;
• The feeler lever made of 316F material is corrosion-resistant ;
• The case of the gauge is at the protection level of IP65;
• The imported sensor chip with original packaging could guarantee the accuracy and serving life of the analyzer;
• Expanded functions can be added to do an accurate measurement on the high-temperature dew point;
• The design of two-stage dust filtration could filtrate the dust and acid liquid efficiently;
• It is with simple operation, long serving life and easy to maintain for features;
• Absolute humidity display type and relative humidity display type are all available;(Please indicate the type when ordering goods).
Technical parameters of Flue Gas Humidity Analyzer:

Test principle	capacity-resistance principle
Display mode	4 bits LED display
Test Range	absolute humidity 0 ~ 40% VOL relative humidity0 ~ 100% RH (Only one pattern can be displayed, so please indicate the type when ordering goods.)
Resolution	0.1%
Accuracy	<±1.5%FS
Repeatability	<±1%
Response time	T90<15S
Operating temperature	Gauge: -10 ~ +50ºC ,probe: 0 ~ 170ºC
Heat tracing type	electric heating (optional) heating temperature: 50ºC ~ 150ºC
Sampling mode	direct insert mode
Analog output	4-20mA.DC(non-isolated output, loaded resistance lower than 500 Ohm) 2-way programmable alarm output (Dry contact type, maximum load220VAC/2A)
Communication Port	RS232
Power supply	AC220V±10% 50/60Hz,power dissipation<15VA
Protection level	316F for feeler lever,IP65 for gauge
Serving life	gauge>36months,sensor>24months(under normal use)
Sample gas composition	no flammable gas,no strongly corrosive gas,dust amount less than 1mg/Nm3
Length of the probe	common size 0.5m,1.0m,1.5m, other size is customizable(<1.8m)
Install mode	plug-in,DN65 standard flange

Founded in 2005, Zhengzhou CY Scientific Instrument Co., Ltd. is a company specializing in the development and production of laboratory technology research equipment. The products are mixed, pressed, burned, cut, ground, polished, coated, analytical equipment and related consumables. Products include laboratory sintering equipment, coating equipment and so on. At present, it has been exported to 25 countries and regions such as the United States, Europe, and Southeast Asia, and has been well received by various scientific research units.
We have a mature technology research and development team, the number of technicians is 33, the company has 150 people, more than 500 square meters of office space, the factory covers an area of about 1,500 square meters located in Zhengzhou High-tech Zone Electronic Industrial Park. The products are mainly located in the research market, serving scientific research in the labs of universities and colleges, and can also customize products according to your needs.
Q. Are you a manufacturer or a trading company?
A. We are professional laboratory instrument manufacturers, have their own design team and factory, have mature technical experience, and can guarantee the quality of products and the optimal price.
Q. How is your company's product after-sales service system?
A. The product warranty period is 12 months, we can provide lifetime maintenance. We have professional pre-sales and after-sales departments that can respond to you within 24 hours to resolve any technical issues.
Q. How long is your delivery time? If I want to customize the instrument, how long does it take?
A.1. If the goods are in stock, it is 5-10 days. 2. We can provide customized services for our customers. It usually takes 30-60 days depending on the specifications of the custom instrument.
Q. Our country's power supply and plug are different. How do you solve it?
A. We can supply a transformer and plug according to your local requirements according to the power plug of different countries.
Q. How to pay?
A.T / T, L / C, D / P, etc., it is recommended to use ****** Trade Guarantee.
Q. How is the package of goods? Delivery methods?
A.1. Standard export fumigation sign wooden box packaging 2. Express, air, sea shipping according to customer requirements, find the most suitable way.
More questions, please contact customer service.
