High-Performance Zn85Al15 Alloy Thermal Spray Wire for Wind Towers

Product Description

The Wind Tower Clean Energy Metal Thermal Spray Wire - Zn85Al15 Alloy, is the perfect solution for wind tower maintenance and repair. This high-quality zinc aluminum wire is specifically designed for metal thermal spray applications, making it an ideal choice for wind tower wire needs.
ZnAl(Zinc alloy wire) is a product, which consists of 85% zinc and 15% aluminum by weight. It creates the optimum corrosion resistance against sodium chloride (salt), and sulfur dioxide in marine environments. It is the optimal protection against salt. An ideal anti-corrosion protective coating of seawater.
ZnAl15 wire (Zinc-aluminium wire )is the best for spraying, As corrosion protection spraying wire, which is suitable for arc and flame spraying processes, was used as a coating sprayed onto the steel. The alloy produces a coating with the best anti-corrosion characteristics of both metals for optimum corrosion protection along with many uses as a solder wire.
Product code:ZA
Chemical composition:

Item	Main elements (%) (min)		Impurities (≤)%(max)
	Zn	Al	Fe	Pb	Cd	Cu	∑
ZA15	REMAINING	14-16	0.05	0.005	0.002	0.01	0.1

Mechanical characteristics:

Item	Form	Tensile Strength Rm (N/mm2)	Elongation After Fracture A 100mm(%)	Specific Gravity (g/cm3)	Melting Range (ºC)	Volume Resistivity (mΩ·mm2/m) 20ºC
ZA15	COLD-DRAW(Y)	≥ 100	≥ 30	5.6-5.8	382-455	≤ 56
ZA15	ANNEAL(O)	≥ 200	≥ 30	5.6-5.8	382-455	≤ 56

Diameter: 1.0mm≤Ф≤4.76mm

DIAMETER	PERMISSIBLE
(MM)	VARIATION
1.0≤Ф≤1.65	+0.00,-0.03
1.65<Ф≤2.00	+0.00,-0.04
2.00<Ф≤2.30	+0.00,-0.05
2.30<Ф≤3.20	+0.00,-0.06
3.20<Ф≤4.76	+0.00,-0.07

Product packing:

Hard paper drum	100-230 kg	outer diameter 550 mm, inner diameter300mm, variable height
Hard paper drum	20-50 kg	outer diameter 400 mm, inner diameter190mm. variable height
Plastic spool	15 kg	flange270mm, width103mm, center hole:55mm
Steel drum	250 kg	outer diameter 560 mm, inner diameter310mm, height 800mm
bundle	20-25 kg

Pallet will be used, such as 1100mmX1100mm, 1200mmX800mm, 1000mmX1000mm, 800mmX800mm. http://tianlong-damno.en.made-in-china.com/product/VEkpdZcbfUWh/China-Zinc-wire-Metal-spray-metarials-factory-in-China.html
Thermal spraying with Zinc-aluminium alloy wire Zn85Al15 can be easily applied to a properly blasted surface up to 0,5 mm thickness in just one application. The coating is dry on contact allowing sealers and/or topcoats to be applied immediately when specified. One application can last over 15 years without the need for maintenance. Long-lasting protection of the surface.
