Silver Foamed Aluminum Foam Soundproofing Ceiling Tiles

Product Description

Product Description Aluminum foam sheet is a type of aluminum sheet with a porous structure, also known as aluminum foam or aluminum foam material. It is usually made from pure aluminum or aluminum alloy through a mixture of aluminum powder, foaming agent and other additives.
The process of making aluminum foam panels usually includes the following steps: first, aluminum powder is mixed with blowing agents, thickeners and other additives to form the raw material of aluminum foam material. Then, the mixture is injected into a mold and foamed and cured at a certain temperature and pressure to form a solid structure of the aluminum foam material. Finally, the final aluminum foam sheet product is formed through processes such as cutting, trimming and surface treatment. Product Parameters

product details of aluminum foam
Ultra-light/low Weight	Pore diameter	Main 5 - 10 mm
	Density	0.25g/cm 3 - 0.85g/cm 3
	Porosity	68% ~91%
	Thickness	6 -300 mm
	Size availability	500*500mm, 600*600mm, 1000*500mm, 1200*600mm. Biggest size is 2400*800mm
	Shape	mainly, panel; customize special shape acceptable
Weather Resistance	Corrosion resistance	Excellent
	Moisture absorption	0.00%
	Heat / non combustion property	A1 grade
	Thermal conductivity	0.25 ~ 0.62W/M.K
	thermal expansivity	19.34*10 -6/ °C
Green Environmental Protection	Non toxicity,100% recyclable,Easy to process and installation
Excellent Hiding Property	After surface spray absorbing material treatment
Excellent Acoustic Performance	Sound insulation (20mm Thickness)	20 ~40 db
	Sound absorption (1000Hz -2000Hz)	40% ~ 80%
Electromagnetic Shielding	Excellent

Product Feature
Lightweight: Our aluminum foam sheet is incredibly lightweight, making it much lighter than solid aluminum sheets. Its porous structure and low density make it ideal for applications where weight reduction is crucial, such as aerospace and transportation.
High Strength: Don't be fooled by its lower density! The evenly distributed pores in the structure of our aluminum foam panels create a strong network structure. This gives our panels high strength and rigidity, with resistance to compression and bending.
Good Energy-Absorbing Properties: Thanks to its porous structure, our aluminum foam panel has excellent energy-absorbing properties. It can absorb and disperse energy when subjected to impact or extrusion, acting as a buffer and providing protection. That's why it's widely used in collision protection and military applications.
Good Thermal and Acoustic Insulation: The porous structure of our aluminum foam panel offers remarkable thermal and acoustic insulation properties. It reduces heat conduction and sound transmission, making it perfect for building insulation and sound control.
Corrosion Resistance: Our aluminum foam panel is made of pure aluminum or aluminum alloy with exceptional corrosion resistance. It can withstand oxidation, corrosion, and even harsh chemical substances. It's the ideal choice for applications in challenging environments.
High Processability: Our aluminum foam sheet can be easily processed using conventional metal processing methods like cutting, drilling, and welding. It can be customized in shape and size to meet your specific needs, making it adaptable to various application scenarios. Application Aluminum foam panels are widely used in aerospace, transportation, construction, electronic and electrical appliances, military protection and other fields due to their light weight, high strength, energy absorption properties as well as good thermal and acoustic insulation and corrosion resistance.
