High Efficiency Rocker Rotary Transfer Machine

Product Description

Product features
1. The whole flat rail body is designed with HT250 cast iron resin sand, 2 aging treatment, small deformation, high stability, rigidity and torsion resistance.
2. This machine tool has the characteristics of high precision, high speed, high rigidity, humanized design, convenient and comfortable operation, novel and beautiful shape, convenient maintenance, high production efficiency, integration of machine, electricity and liquid.
3. X, Z axis servo motor through flexible coupling with precision ball screw directly connected, high precision, fixed on both ends of the screw, improves the support stiffness of the brackets, make frequent high-speed positioning, during the heavy cutting screw to minimize the distortion degree, the bearing is made of high quality domestic screw 60 degree Angle contact pairs precision bearing, high speed, high precision.
Standard configuration
1.K1000 system or GSK980 system 2.Taiwan HIWIN linear guide rail
3. gang tools 4.pneumatic elasticcollet
5.high precision bearing

Technical parameters	Item		Unit	CK4030Q
processing range	the max. turning diameter of machine		mm	Φ340
	the max. turning length		mm	300
	the max. turning diameter(plate)		mm	Φ340
spindle	end model of spindle		/	A2-5/unit spindle
	through-hole diameter of spindle		mm	Φ48
	the highest speed of spindle		r/min	5000/3000
	rated power of main motor		kw	3.7/5.5
	clamping form		/	manual/pnuematic/hydraulic
feed	X axis rapid traverse speed		m/min	20
	Z axis rapid traverse speed		m/min	20
	X axis route		mm	320
	Z axis route		mm	300
machine tool accuracy	positionaI accuracy		mm	0.012/0.016
	repeated positionaI accuracy		mm	0.004/0.006
(gang tool)tool post	tool post form and stationquantity		/	linear gang tool post(standard configuration)
			/	vertical tool post(option configuration)
	tool size	tool square size	mm	20*20
		boring tool pole diameter	mm	Φ25
machine dimensions	machine weight		kg	1300
	dimensions L*W*H		mm	1950*1400*1550

About US:
Taizhou Yihong co .,ltd which is located in yuhuan city ,(china valve city automobile parts city) . The company is a professional production and sales of advanced machine tools group company. We have 4 factories in China mainly producing brass rod /ingot making machine ,automatic forging machine, cnc transfer machine ,automatic cnc machine ,ball making machine and automatic assembly machine,The whole line processing equipment. We have a group of professional engineers in charge of technology, manufacture, installation and testing, so we can guarantee that our machines will put on good performance based on high quality. We can provide customers with full services and technical consultation upon different requests in 24 hours. YIhong company would like to offer the best machines, and build ourselves as the bridge and window for both overseas and domestic enterprises and customers.Products are exported to Russia, India, Iran, Turkey, United Arab Emirates, Bolivia, Chile, Uzbekistan, Saudi Arabia, Syria, Jordan, Indonesia, Singapore, Thailand, Pakistan, South Africa, Egypt, Nigeria, Kenya and other countries .We do believe we can create a win-win situation for both sides as long as we have come to a cooperation consensus. "Together we stand still, Divided we fall". This is what we uphold while treating our partners. Clients from all over the world are warmly welcome to build business relations, cooperate and develop together with us. Please feel free to contact us for details.
Before sales
our professional tachnical recommed the right machine and can also customise special machine as customer's requirement and special parts
sales following
during machine production watching the machine quality and testing machine and take pictures or make video for customer checking
After sales
we will send technical go to customer's factory to install and adjust machine
we have after-sell service to supply all life-time machine maintance and repairment service
FAQ:
Q1. How can I get a quotation?
A. Leave us massage with your purchase requirements and we will reply you ASAP. And you may contact us directly by Trade Manager or Telephone.
Q2. Can you provide customized machine or SPM (Special purpose machine)?
A. Yes, we provide smart solutions for our customer, in order to increase efficiency.
Q3. Can you provide training for operation CNC machines?
A. Yes, free training in our factory is available.
Q4. How about your price?
A. Send me details about what you need, you will get the best price in China. The price is competitive over the world.
Q5.What's your warranty terms?
A.One year warranty for normal use and we supply maintenance for free.
Q6.What kind of payment methods do you support?
A. We support payment methods such as L/C, T/T, DP, DA and so on
Q7.Do you have a professional technician?
A. Yes, our company has a team of professional engineers from Taiwan.
If you interested,please contact me.
Contact:Alice
