Precision Crusher Grinding Equipment with Syntec CNC and Magnetic Chuck

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
We embrace a rigorous policy of perpetual enhancement for all our products, safeguarding our ability to adjust specifications, mechanics, or designs at any time without prior notice or obligation.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd., established in the innovation hub of Dongguan City, Guangdong Province, draws from 30 years of Taiwanese expertise in grinding machine manufacturing, amassing a wealth of technical prowess and experience. As the field of CNC machine tools accelerates, the focus is now on achieving unprecedented high-speed, high-precision, integrated, intelligent, open, parallel-driven solutions, all while prioritizing networking and eco-friendly practices—a visionary direction for the future of CNC machine tools. Dongguan Chengyu Machinery Technology Co., Ltd. stands at the forefront of machine tool production and processing, as well as crafting exceptional machine tool accessories. Guided by our core philosophy of 'technology, innovation, reliable' and driven by a meticulous quality policy, we are committed to delivering superior products and exemplary customer service. Our approach begins by understanding clients' process intricacies, technological needs, production types, and quality benchmarks. By leveraging advanced design and production technologies, we continually enhance product applicability and broaden the possibilities within the numerical control industry, aiming for high automation, precision, and quality. Our comprehensive quality management system, coupled with first-rate equipment and exceptional technology, ensures unparalleled product positioning. In tune with market demands, Chengyu Machinery excels in crafting high-precision CNC surface grinding machines, CNC forming machinery, four-axis punch grinders, vertical slider grinders, and gantry rail grinders. We also specialize in designing and manufacturing industrial robots, automated production lines, and integrated applications. Here is a concise overview of our CNC grinding machine series: I. HS series 618 / 250 / 3060 / 4080 / 40100 (available in both servo and hydraulic configurations) Processing capabilities include surface grinding and precise grooving. Featuring an innovative patented hydraulic control system (hydraulic variant). Functions encompass a versatile grinding program: from flat surface refining to extensive groove cutting. Feed modes are versatile, offering front/back and left/right selection, with each grinding program allowing memory feed mode configuration. Automatically responsive grinding wheel overload protection, facilitating automatic shutdown in critical scenarios. II. Available in (servo and hydraulic variants) Boasting capabilities for surface grinding, intricate grooving, and combined scheduling. Incorporating a pioneering hydraulic control system (hydraulic variant). Features include a spectrum of grinding programs: surface refinement, intricate groove carving, sole and side grinding, with unrivaled unequal distance and depth displacement grinding. For precision, our grinding wheel dressing includes base plane dressing with automated settings for rough and fine grinding dressing time and amount—enabling automatic dressing and compensation during the grinding cycle. Choose between front/back and left/right feed modes, with each grinding program retaining memory feed mode. Capable of producing equidistant grooves, with flexible non-equidistant and unequal specifications. 3. Our advanced four-axis CNC grinding machines are categorized into horizontal and vertical models. Processing types range from arbitrary equal division to sophisticated skipping tooth processing. For waist circle processing, simply input AB size. For triangle fillet tasks, enter the inscribed circle size B and desired fillet size R. For quadrilateral fillet work, provide side length A, side length B, and fillet size R. For eccentric circle configurations, specify the eccentricity along with starting and ending diameters. For circular structures, input starting and ending diameters as needed. Arc – Effortlessly enter the desired arc size and specify the perfect rotation angle for impeccable precision. Step Difference – Seamlessly adjust the rotation profile and other parameters for top-notch performance. Processing Schedule – Easily save it as a processing file, ensuring effortless retrieval and streamlined operations every time.
