Paper Lid Machine/Paper Cup Making Machine/Automatic Bowl Paper Cup Forming Machine (JBZ-S30)

Product Description

1. Equipment Name: Automatic bowl paper cup forming machine
2. Description:
Model JBZ-S30 Ultrasonic Two-PE Paper Bowl Forming Machine is an automatic machine with multi-working station, which has the function of photocell detection, failure alarm, counter and the advantages of humanism design, safer operation and easier maintenance.
It makes both one-side-PE-film-coated and two-side PE-film-coated paper bowls after running a whole procedure of automatic pre-printed-fan-shape-paper feeding, two-step pre-heating, bowl-side-body sealing(ultrasonic wave), silicone-oil lubricating(for top curling), bottom punching, two-step bottom heating, bottom pre-folding, bottom knurling, top curling and bowl discharging.
It is an ideal equipment of making soup paper bowls, noodle bowls, bigger paper cups and other large food cone-shaping containers etc.
3. Technical Specification:
HS. Code: 8441309000
Paper bowl Size: 20--50oz, height up to 125 mm (mold exchangeable);
Raw Material: One-side or two-side PE(polyethylene) film coated/laminated paper;
Suitable paper weight: 140GSM--450 GSM (Recommend 190--300 GSM);
Rated Productivity: 35--40 PCS / minute;
Total Power: 9 KW;
Power Source: 220V/380V 50Hz or other required;
Total Weight: 1800 Kg;
Package Size (L x W x H): 2830 X 1450 X 1900 mm;
Electric Control Box Size: 750 X 570 X 1070 mm
Working Air Source: Air pressure: 0.6MPa, Air Out-put: 0.6m3/minute;
Making Paper Bowls, An air compressor is demanded.
