Module spare parts PROSOFT MVI94-GSC

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

PROSOFT MVI94-GSC

.CB810 is a USB 2.0 to Fast Ethernet converter. It converts a standard USB Host port on a PC to a standard network adapter (network card). To enable project transfer etc. between Panel 800 with built-in Ethernet RJ45 port and a PC using the USB port on the PC; connect the CB810 adapter as follows. The USB Type A connector on CB810 is connected to a USB Host port on a PC. Crossover Ethernet patch cable (twisted pair cable) with RJ45 connectors is connected between the Ethernet RJ45 port on CB810 and the Ethernet RJ45 port on the Panel 800. Section 3 Installation Connections to the Controller 3BSE043449R501 25 Follow the instructions in the manual for the operator panel to make settings for the Ethernet / TCP/IP project transfer in the configuration tool. Technical Specifications • Single chip USB to 10/100 Mbps Fast Ethernet. • Compliant with USB specifications 1.0, 1.1, and 2.0. • Full/High Speed USB Device with bus power capabilities. • IEEE 802.3u 100BASE-T, TX, and T4 compatible. • Embedded 7K*16 bit SRAM, 256*16 bit SRAM and 8 FIFOs. • Supports both full-duplex or half-duplex operation Fast Ethernet. • Supports suspended mode and remote wake up. • Optional PHY power down mode for power savings. • Supports automatic loading of Ethernet ID, USB Descriptors and Adapter Configuration from EEPROM on power-on initialization. • Ethernet PHY loop-back diagnostic capability. Connections to the Controller For information about the cables to be used when connecting the operator panel to the controller, please refer to the help file for the driver in question. Other Connections and Peripherals Cables, peripheral equipment and accessories must be suitable for the application and its environment. For further details or recommendations, please refer to the supplier. CB810 is not approved for fixed installation or for use when the Panel 800 is installed and/or running. It should only be used for project/file transfer between a PC and the Panel 800. CB810 cannot be connected directly to the Panel 800. When using a compact flash card, do not remove the card when the busy indicator is illuminated. the files to the internal card; select YES to this question. Settings in Panel Builder 800 The size of the internal memory card must be entered in the configuration tool for the operator panel. 1. Select Setup/Terminal Options. 2. Enter the size of the internal memory card under Memory card settings/Internal. Caution - If the CPU card and power card is disconnected from each other for a longer period of time, the panel may not boot when it is reassembled again. To remedy this problem, a hardware reset needs to be performed by setting the mode switch no. 4. Internal Compact Flash memory card slot Section 3 Installation Expansion Module for Profibus DP 3BSE043449R501 21 3. Click OK to close the dialog. Expansion Module for Profibus DP An expansion module can be used for connection via Profibus DP. Observe precautions for handling electrostatic sensitive devices. Expansion Module for Profibus DP Section 3 Installation 22 3BSE043449R501 Space Requirements Installation 1. Unpack and check the delivery. If damage is found, notify the supplier. 2. Disconnect the operator panel from the power supply.
