Wheat Flour Pasta Dough Kneading Mixing Machine

Product Description

China wheat Flour Pasta Dough Kneading machine
12.5-200kg\time Horizontal type food flour powder dough mixer kneading machine
Description: Dough making machine is mainly used by a wheat flour and water: the ratio of 0.38-0.45, according to the user processing requirements (sometimes plus cooking oil, canteens and other food and food additives) mixed into the dough widely used in canteens, restaurants and pasta processing pasta processing units, is an alternative to the manual, reduce labor intensity, ideal equipment to meet the people's food hygiene requirements, can also be used for stirring and mixing with other similar materials.
Structure and working principle:
Structure composed of several parts, manual dump, inverted switch direct control motor reversing, easy to operate, 12.5I, 20I, 25III, 25IV, 30,50III, 50IV, 75I-type and surface machine motor built-in structure, space small, compact structure.
HWY75II, 100II, 150I-type and surface machine main frame, side bucket, consisting of automatic tipping mechanism, electrical control and so on. Transmission parts turbo gear and chain drive, automatic dump, built-in motor, compact structure, electrical control through the control button, AC contactor, control of the main and auxiliary motor forward, reverse, stop, limit switch from time to dump limit bit protection. It is widely used in large and medium-sized catering units, is the ideal production line equipment.
HWY75II, 100II, 125,150I type and surface machine main frame, side bucket, consisting of the main turbine case, turbine dump boxes, electronic control part. Turbine box with closed structure, effectively guarantee the mounting accuracy, fully lubricate the parts, increasing the life and reduce the incidence of failure. Automatically switch to dump bodies turbine gear box, reducing the dump noise. Blender using axial positioning and seal structure to solve the problem blender grind axial movement and the end of black faces. Built with motor structure, turbine shaft directly connected with the agitation, reduced power consumption, compact, medium height fuselage, deputy motor forward, reverse, stop, travel limit switch from the protective effect when tipping. Simple structure, beautiful appearance, medium and large catering units, and the ideal pasta manufacturers equipment.
HWY30,50IV type and surface machine is my factory patented product, main frame, side bucket, foot dump body composition, electrical control and so on. Transmission part adopts arc tooth gear and chain drive turbines, high efficiency, low noise, long life. Built-in motor, compact structure, good sealing, electrical control through the control button, AC contactor control motor Story, reverse, stop, leakage circuit breakers from overload, short circuit, leakage protection. The machine is 20,35,50 type and surface machine upgrade products
works:
Flour evenly mixed under agitation blender with water, first of all, the formation of irregular small colloidal aggregates, thus small aggregates bonded with each other, and gradually formed a large number of scattered clumps, with the blender to cut the dough in a row folding, rolling, stretching and gentle series role, and made a smooth surface, has a certain elasticity, toughness and an ideal extension of the dough.
Dough kneading machine
The WSHW series dough mixer is the main equipment for food processing. It can make the flour ad water(some times with the edible oil, sugar, other food or food additives)mixed into dough. Its application plays a very important role I saving labor, and increasing of efficiency. <o: P>

Model	Cubage of dough bucket (m 3 )	Flour Capacity (kg)	Dough Capacity (kg/h)	Power (kw)	Dimension (mm)	Weight (kg)
WS WT12.5	0.064	12.5	125	1.5	750*450*620	120
WS WT15	0.080	15	150	1.5	760*520*830	125
WS WT25	0.098	25	200	1.5	870*520*830	130
WS WT50	0.134	50	400	3	1050*700*970	180
WS WT75	0.192	75	525	3	1160*600*1000	220
WS WY50	0.134	50	400	1.5	980*520*980	175
WS WY75	0.201	75	450	2.2/0.75	1180*680*1350	500
WS WY100	0.236	100	600	2.2/0.75	1250*680*1350	510
WS WY150	0.366	150	900	4/0.75	1450*800*1500	620
WS WY200	0.420	200	1200	5/0.75	1750*800*1560	760
