Product Overviewpurification wastewater sludge treatment lamella tube settlerThe tube settler produced by using EPR copolymer plastic as the material, it was hot drawn into slope tube by a infrared thermal machine,and then using patented technology and high frequency to weld into a whole product.Inclined tube is mainly used for a variety of precipitation and sand removing. For a decade,it is a water treatment device that's widely used in the drainage works. It has the advantages of being suitable for a wide range, high treatment efficiency, small footprint.Tube settlers, also called lamella clarifiers, are used to remove solids in the waste water treatment.Tube settlers use multiple tubular channels sloped at an angle of 60° and adjacent to each other, which combine to form an increased effective settling area. This provides for a particle settling depth that is significantly less than the settling depth of a conventional clarifier,reducing settling times.Tube settlers capture the settleable fine floc that escapes the clarification zone beneath the tube settlers and allows the larger floc to travel to the tank bottom in a more settleable form. The tube settler's channel collects solids into a compact mass which promotes the solids to slide down the tube channel.FEATURES AT A GLANCEpurification wastewater sludge treatment lamella tube settler1. Ideal in dirty water applications.2. Far more forgiving of poor water distribution caused by clogged or missing nozzles.3. Water easily redistributes itself.4. Ideal in dusty or wooded environments.5. Easy maintenance.6. Long service life.7. High-temperature designs available.8. Designs available for heavy ice loads.PRODUCT SPECIFICATIONSApertureThicknessQuantity (pc/m2)Weight (kg/m2)Surface Area25mm0.4mm623013935mm0.45mm623513935mm0.4mm422210980mm0.45mm422510950.5mm422810950mm0.4mm30178770.45mm3017.58780.5mm3019870.6mm30228780mm0.7mm2019.5500.8mm202250Production ProcessSIMILAR PRODUCTSFAQWhy Choose Us?1. Highest qualityWe are the manufacture who adopts import raw materials. It is amazing, and with cheap price and guaranteed quality.2. Most competitive priceWe can adjustment the price according to your market demand’s changes,and also can launch a series of promotional activities in a bad economic environment.3. ProfessionalWe are special in producing and sells, as development, methods, and handling.4. Best serviceAnswering emails or solving questions timely. Delivery and update information on time. Trust, good quality and service are the basic of long term business.
