High Speed Mixing System for PVC Resin Powder (SHR)
| US$2,200.00-20,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
SHR
Application
Granules, Powder
Application Area
Chemical, Daily Chemical
Certification
CE
Condition
New
Cooling Method
Water Cooling
Heating Method
Self Friction and Electrical Heating
Main Material
Stainless Steel
Mixing Capacity
10-6000L
Mixing Drum Shape
Circular Groove
Speed Control
Variable Speed
Speed Range
0-1400 Rpm
Stirring Type
Forced
Warranty
1 year
Working
High Speed Mixer
Mixer Type
Agitator
Layout Type
Verticle
Operating Type
Cycle Operating
Transport Package
Wooden Package
Specification
CE
Trademark
Jiahong
Origin
Zhejiang of China
HS Code
8477800000
Production Capacity
50, 000 Psc/Year
Packaging & Delivery
Package Size
300.00cm * 180.00cm * 240.00cm
Package Gross Weight
5000.000kg
Product Description
Product DescriptionHigh Speed Mixing system for pvc resin powder
Futures:
1. Used for the processes of mixing, drying and drying in the industries of plastic, rubber, chemical and the place of lab as well.
2. The mixer lid adopts double sealed.
3. with the heating ways of self-friction and electric, etc.
4. with discharging ways of temperatureautomatic control and manual control.
5. Paddles are entirely made of stainless steel and through dynamic and static balance test.
6. The electric control system adopts the components of famous brand.
Product Parameters
Technical parameters:
| Model | Capacity (L) | Effective capacity (L) | Motor power (kw) | Main shaft speed (r/min) | Outook size (mm) | Heating method | Discharge method |
| SHR-5A | 5 | 3 | 1.1 | 1440 | 620× 300× 730 | self-friction | manual/self-motion |
| SHR-10A | 10 | 7 | 3 | 1440 | 1200× 300× 830 | self-friction | manual/self-motion |
| SHR-25A | 25 | 20 | 5.5 | 1440 | 1200× 350× 850 | electricity/self-friction | manual/self-motion |
| SHR-50A | 50 | 35 | 7/11 | 750/1500 | 2100× 700× 1100 | electricity/self-friction | self-motion |
| SHR-100A | 100 | 75 | 14/22 | 650/1300 | 2100× 800× 1510 | electricity/self-friction | self-motion |
| SHR-200A | 200 | 150 | 30/42 | 475/950 | 2400× 850× 1580 | electricity/self-friction | self-motion |
| SHR-300A | 300 | 225 | 40/55 | 475/950 | 2800× 1080× 1680 | electricity/self-friction | self-motion |
| SHR-500A | 500 | 375 | 55/75 | 430/860 | 3060× 1150× 1880 | electricity/self-friction | self-motion |
| SHR-800A | 800 | 600 | 83/110 | 370/740 | 3385× 1380× 2750 | electricity/self-friction | self-motion |
| SHR-1000A | 1000 | 750 | 110/160 | 325/650 | 3460× 1140× 2900 | electricity/self-friction | self-motion |
| SHR-1300A | 1300 | 975 | 132/200 | 250/500 | 3600× 1420× 3100 | electricity/self-friction | self-motion |
| SHR-200C | 200 | 150 | 30/42 | 650/1300 | self-friction | self-motion | |
| SHR-300C | 300 | 225 | 47/67 | 475/950 | self-friction | self-motion | |
| SHR-500C | 500 | 375 | 83/110 | 500/1000 | self-friction | self-motion |
Detailed Photos
