Injection Machine 730t by C Screw

Product Description

Injection machine 730T by C screw
Specification for 730t :

		A	B	C
INJECTION UNIT
Screw diameter	mm	90	95	105
Screw L/D ratio	L/D	23.2	22	19.9
Shot volume(theoretical)	cm3	3181	3544	4330
Injiection weight(ps)	g	2895	3225	3940
Injection rate	g/s	574	640	781
Injection pressure	Mpa	195	175	143
Screw pressure	rpm	115
CLANPING UNIT
Clamping force	kN	7300
Open stroke	mm	950
Space between tie bars(W×H)	mm	950×950
Max.Mold height	mm	960
Min.Mold height	mm	400
Ejector stroke	mm	280
Ejector force	kN	210
OTHERS
Max.Pump pressure	MPa	16
Pump motor power	kW	56+56
Heating power	kW	56.7
Machine dimension(L×W×H)	m	11.43×2.40×3.14
Oiltank cubage	L	1200
Machine weight	t	37

01 WHY CHOOSE MENGKWA?
1) Mechanical and electric parts of machines for our machines are from famous brands with reliable and stable quality .
2) Machine structures and applicant parts are heavy duty type .
3) Technologies of machines are developing to be much more energy saving and higher production output .
4) Engineers for installation and training are both available in China and abroad .
5) Our after service is available in 24hours by team group to every customer .
6) Our machines reach to 54 countries all over the world since 1996 .
02 TERMS OF PAYMENT
30% deposit and 70% balance before shipment after machine testing approved by customer .
03 PACKING AND LOADING
Safe packing for container loading OR heavy duty iron frame fixing OR wood cases packages .
04 AFTER-SALE SERVICE
1) 24 hours technical support by email, call, video.
2) Warranty for one year after 12 months of shipment.
3) Installation and commissioning engineer will provide the tech long machine, and machine operation of the buyer's personnel on-site training, troubleshooting and machine maintenance. The factory offers free installation training for a week the company engineers, beyond a week, the salaries borne by the customer engineer the factory.
