Vertical Autoclave Steam Sterilization Machine Vertical Autoclaves

Product Description

Product Description Autoclaves are equipment for sterilizing widely used in microbiology, medicine, podiatry, tattooing, body piercing, veterinary science, mycology, dentistry, and prosthetics fabrication. They vary in size and function depending on the media to be sterilized.
Safety Features:
1. Over pressure. Safety valve can automatically open to release pressure.
2. Over temperature. The system will power off automatically.
3. Door sensor. Sensor at door closing position, to check the door status. If door is open, operation will stop.
4. Anti-dry out function. If water level is too low, system will power off and error code displays on screen.
5. Over current. over voltage or electric leakage protection apparatus-air switch.
6. Door cover.The door is covered with safety shell made of thermal insulation material, which can protect operator from burning by heat and looks nice.
* Water inlet filter to keep high water quality(except HW-B150/200II).
* Optional printer for recording sterilization data.
* LED screen displays all steps of full process as well as error codes.
* Independent quick service window, easy for repairing and maintenance.
* Automatic selecting quick or low exhaust to avoid sterilization liquid overflowing.
* Sterilization programs for dressings, equipment, rubber, culture medium, waste, etc.
* Hand wheel type of quick-open door structure, self-expandable sealing ring, easy operating and safe.
* Complete process of filling water, dynamic pulse exhaust, heating, sterilizing, draining and drying runs automatically.
* Adopting certain temperature(98~102ºC) exhaust method and dynamic pulse exhaust method to empty the cold air inside chamber for ensuring steam saturability.
* Inner stainless steel water tank for water and steam to circulate inside. Steam dose not exhaust during sterilization, so as to keep the outside clean and dry(except HW-B150/200II).
*Drying function (except HW-B150/200II)
Product Parameters

Model	HW-Z12N	HW-Z18N	HW-Z24N
Capacity	12L	18L	24L
Chamber Size(mm)	φ200*360	φ245*350	φ245*450
Sterilization Class	Class N (according to EN 13060 standard)
Sterilization Temp.	121°C, 134°C
Drying Procedure	Heat drying
Display	LED display
Control Precision	Temperature: 1°C
	Pressure: 0.1 bar
Safety System	Hand lock door
	Relief valve in case of over pressure
	Pressure or temperature over load protection
	Alarm for system failure, finish reminding
Tray Holder	3 pcs SS trays on SS shelf
Chamber	SUS304
	Max working pressure: 2.3bar
	Min working pressure: 1.1 bar
	Max temperature: 145°C
Ambient Temp.	5~40°C
Noise	<50dB
Power	1600W for 220V, 1200W for 110V
Power Supply	Standard: 220V±10%, 50/60Hz; Optional: 110V±10%, 50/60Hz. Wiring Method: Plug
External Size(W*D*H)mm	560*450*400	560*450*400	670*450*400
Package Size(W*D*H)mm	650*515*470	650*515*470	760*515*470
Gross Weight(kg)	38	40.5	45.5

Detailed Photos
